Fixing tie with pipe/tube holder, ⌀100.0mm, black, 200pcs.


Art.-No. 156-03093

| X120RIAHC2T-PA66HIRHS-BK

 |

Copied
2-piece fixing tie, 360° rotatable, a cable tie in combination with an AHC to route and fix harnesses.
T120RIAHC( )TCR
T120RIAHC( )TCR
T120R cable tie assembled with an IAHC.

    • Inside serrated cable tie with closure clip
    • High tensile strength around cable bundles
    • Smooth, rounded head design
    • Provides a secure fastening with no lateral movement
    • For fixing and bundling convoluted tubes and pipes
    Downloads e-Learning
    Application Offering a simple and secure method of attaching cables together. Originally designed for the automotive industry, these products are used in a wide range of applications.
    Colour Black (BK)
    Identification Plate Position none
    Key product features rotatable, for multiple routing, removable
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
    Min.Tensile Strength 535N
    PART DESCRIPTION X120RIAHC2T-PA66HIRHS-BK
    Pack Content 200pcs.
    Package Content packed in bag
    Product Family AHC-Series
    Product Group 2-piece fixing ties with automatic harness clip
    Type X120RIAHC2T
    Attach to ⌀ 11.0-20.0
    Bundle ⌀ max. 100.0mm
    Length (L) 369.0mm
    Thickness (T) 1.6mm
    Width (W) 7.7mm
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 4031026648538
    UNSPSC Key 39121703
