Cable clip with pipe/tube holder, Dmin=4.0mm, Dmax=5.5mm, nomØ=5.0 mm, nomØ2=12.0 mm, black, 2000
Art.-No. 156-02286 | MOC5FMOC12M-PA66HIRHSUV-BK |  세부

Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Pack Content 2000
Package Content packed in carton
PART DESCRIPTION MOC5FMOC12M-PA66HIRHSUV-BK
Variant Clip to Clip
Bundle Diameter max (metric) 5.5mm
Bundle Diameter Nom. (ND) 5.0 mm
Bundle Diameter Nom. 2 (ND2) 12.0 mm
Bundle ∅ 2 max. 13.8mm
Bundle ∅ 2 min. 10.5mm
Bundle ∅ min. 4.0mm
Depth (D) 10.0mm
Height (H) 22.1mm
Length (L) 33.6mm
Length (L2) 19.3mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free Yes
Operating Temperature -40 °C to +110 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised Yes
GTIN-13 / EAN 4031026717258
Packaging 1 - Weight (kg) 201.88kg
Packaging 3 - Height (m) 0.137m
Packaging 3 - Length (m) 0.519m
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0218m³
Packaging 3 - Width (m) 0.306m
UNSPSC Key 39121702
Art.-No.: 156-02286 세부 문의
