Cable clip with pipe/tube holder, Dmin=7.0mm, Dmax=9.0mm, nomØ=8.0 mm, nomØ2=5.0 mm - 9.0 mm, black, 2500
Art.-No. 156-01833 | MOC8FLOC5-9-PA66HIRHSUV-BK 세부

Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Pack Content 2500
Package Content packed in carton
PART DESCRIPTION MOC8FLOC5-9-PA66HIRHSUV-BK
Variant Clip to Clamp
Bundle Diameter max (metric) 9.0mm
Bundle Diameter Nom. (ND) 8.0 mm
Bundle Diameter Nom. 2 (ND2) 5.0 mm - 9.0 mm
Bundle ∅ 2 max. 9.0mm
Bundle ∅ 2 min. 5.0mm
Bundle ∅ min. 7.0mm
Depth (D) 12.0mm
Height (H) 23.6mm
Height (H2) 15.20mm
Length (L) 38.50mm
Length (L2) 22.2mm
CE Certification No
CSA Certified No
Flammability UL 94 HB
Halogen-free Yes
Operating Temperature -40 °C to +110 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised Yes
GTIN-13 / EAN 4031026715339
Packaging 1 - Weight (kg) 203kg
UNSPSC Key 39121702
