Bundling clip for hole (round), L=50.0mm, SO=32.0mm, natural, 1500pcs.
Art.-No. 151-01238
| SOC12FTOVAL-PA66HIRHS-NA
|
세부
| Bundling Bar Length | 50.0mm |
| Bundling Bar Length | 1.97" |
| Fixing Hole Shape | Oval |
| for Hole ∅ (FH) | 6.2 x 12.2 mm, 6.5 x 12.5 mm, 6.5 x 13.0 mm, 7.0 x 12.0 mm |
| for Panel Thickness min - max | 0.6 - 6.8 mm |
| Height (H) | 20.0mm |
| Height (H2) | 12.9mm |
| Length (L) | 50.0mm |
| Length (L2) | 32.0mm |
| Offset Length | 32.0mm |
| Panel Thickness | 0.02 - 0.27" |
| Panel Thickness max. | 0.6 - 6.75mm |
| Panel Thickness max. (imperial) | 0.27" |
| Panel Thickness min. (imperial) | 0.02" |
| Width (W) | 9.5mm |
다운로드
|
|
|
| GTIN-13 / EAN | 4031026477787 |
| Packaging 1 - Qty | 1500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Weight (kg) | 4.029001kg |
| Packaging 2 - Type | carton |
| Packaging 3 - Height (m) | 0.212725m |
| Packaging 3 - Length (m) | 0.51435m |
| Packaging 3 - Qty | 1500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0347m³ |
| Packaging 3 - Weight (kg) | 4.81kg |
| Packaging 3 - Width (m) | 0.3175m |
| Packaging 4 - Height (m) | 1.22m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 30000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.171m³ |
| Packaging 4 - Weight (kg) | 115.88kg |
| Packaging 4 - Width (m) | 0.8m |
