CTCC IWS corrugated tubing holders
Art.-No. 169-22000
| CTCC-IWS17-MB43-PA66/6HIRHS-GY
|
세부
- Compatible with the IWS corrugated tubings
- Safe and fixe hold of the corrugated tubing
- Easy closing and reopening of the lid
- Cable tie holder on both sides
- Pre-fixation of the corrugated tubing in open status
- Can be fixed with screws and matched to the mounting rails of the control cabinets
- Additional laying - a ground cable on the corrugated tubings possible (through recess in the cover)
- Self-extinguishing according to UL94 HB
More products in this product group:
| Application | CTCC IWS corrugated tubing holders are used in the control cabinet for fastening and guiding. |
| Colour | Grey (GY) |
| Fixation Method | screw-hole |
| Material | Polyamide 6.6/6, high impact modified, heat stabilised (PA66/6HIRHS) |
| Pack Content | 20pcs. |
| Package Content packed in | bag |
| PART DESCRIPTION | CTCC-IWS17-MB43-PA66/6HIRHS-GY |
| Product Family | CTCC IWS corrugated tubing holder |
| Product Group | Corrugated tubing holder |
다운로드
|
|
|
| GTIN-13 / EAN | 4031026638300 |
| Packaging 1 - Height (m) | 0.1m |
| Packaging 1 - Length (m) | 0.22m |
| Packaging 1 - Qty | 20 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00528m³ |
| Packaging 1 - Weight (kg) | 0.19938kg |
| Packaging 1 - Width (m) | 0.24m |
| Packaging 3 - Height (m) | 0.204m |
| Packaging 3 - Length (m) | 0.591m |
| Packaging 3 - Qty | 480 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.048m³ |
| Packaging 3 - Width (m) | 0.398m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 9600 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Width (m) | 0.8m |
