TSRP2-21-1-PVC-WH


Art.-No. 250-62214

| TSRP2-21-1-PVC-WH

 |

Copied
Colour White (WH)
Description HellermannTyton surface raceway systems are the ideal solution for routing communication and power cables. No need to break into existing walls - raceway systems are designed to route cable along wall surfaces. Made of a PVC material, components are durable and affordable; and the one piece construction and adhesive tape backing make positioning and mounting easy. HellermannTyton offers a low voltage TSR system and a power rated TSRP system that are available in three different diameters to accommodate different cable and wire bundle and conduit sizes. Both systems include a complete line of fittings and junction boxes that allow for clean and professional installations. TSRP surface raceway systems are designed to aesthetically organize and route either power or communications cables.
Material Polyvinylchloride (PVC)
PART DESCRIPTION TSRP2-21-1-PVC-WH
Pack Content 10
Package Content packed in pack
Type TSRP2-21-1
UV-Stabilised No
Height (H) 22.48mm
Length (L) 72.49mm
Wall (WT) 1.78mm
Wall (WT) 0.07"
Width (W) 108.46mm
CE Certification No
CSA Certified No
Flammability UL 94 V0
Halogen-free No
Operating Temperature +50 °C
ROHS compliant Yes
Specifications
UL Listed (US and Canada) Yes
UL Listed (US) Yes
UL Recognized (US and Canada) No
UL Recognized (US) No
UL-File Number E211305
GTIN-13 / EAN 4031026722054
Packaging 1 - Qty 10
Packaging 1 - Type bag
Packaging 3 - Height (m) 0.219075m
Packaging 3 - Length (m) 0.6064m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0529m³
Packaging 3 - Width (m) 0.3984625m
UNSPSC Key 39131711
