14/10/2024

Fixing tie for hole (round), inside serrated, ∅32.0mm, black, 500pcs.
Art.-No. 150-74890 | T30RFT6D10-PA66HS/PA66HIRHS-BK Details

  • Pre-assembled 2-piece fixing tie with fir tree foot part
  • Cable tie head can be moved after bundling
  • Easy to assemble without the need for a tool
  • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
  • Fir tree foot part can be used for a variety of panel thicknesses
  • Suitable for use within threaded holes
Show more

Request your individual offer now

Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
Cable Tie Polyamide 6.6, heat stabilised (PA66HS)
Colour Black (BK)
Description These two-piece fixings are supplied ready assembled and offer a simple and versatile method of bundling and fixing cables. The fir-tree base will easily push into pre-punched holes in panels or threaded, blind, holes and offers a very secure fixing. The two-piece design enables the head of the tie to be orientated to the required position to ease assembly, whilst the 'disc' on the top of the fir tree covers the hole and minimises the ingress of water and dirt.
Fixation Method Fir tree for round holes
Foot Part Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION T30RFT6D10-PA66HS/PA66HIRHS-BK
Pack Content 500pcs.
Package Content packed in bag
Product Family Fir tree parts FT6
Product Group 2-Piece Fixing Ties with Fir Tree, with Disc, for Round Holes
Tie Closure plastic pawl
Type T30RFT6D10
Variant Inside Serrated
Bundle Diameter max (metric) 32.0mm
Disc ∅ 0.63"
Disc ∅ 9.8mm
Height (H) 1.1mm
Height (H2) 9.5mm
Length (L) 150mm
Length (L2) 9.8mm
Min.Tensile Strength 135N
Panel Thickness 0.03 - 0.12"
Panel Thickness max. 0.8 - 4.3mm
Panel Thickness max. (imperial) 0.12"
Panel Thickness min. (imperial) 0.03"
Width (W) 3.5mm
Width (W2) 0.4"
for Hole ∅ (FH) 5.8 - 6.2 mm
for Panel Thickness min - max 0.8 - 4.3 mm
for Panel Thickness min - max 0 - 0.1 "
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
Operating Temperature Foot Part (Metric) -40 °C to +105 °C
ROHS compliant Yes
Specifications
UV-Stabilised No
GTIN-13 / EAN 4031026196022
Packaging 1 - Height (m) 0.065m
Packaging 1 - Length (m) 0.36m
Packaging 1 - Qty 500
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00608
Packaging 1 - Weight (kg) 0.517815kg
Packaging 1 - Width (m) 0.26m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 5000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 5.82kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.249m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 60000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.199
Packaging 4 - Weight (kg) 90.84kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121703
