Cable Tie locked by glass fibre pin : KR8/33
Cable Tie locked by glass fibre pin 337x8.0 HS-natural, Article number: 121-83355
Features
- Cable tie without serration to avoid any damage to cables
- Strap is locked into place with a glass-fibre reinforced pin
- Very secure and vibration resistant fixing
- Available in various materials, colours and almost every length
- Cable ties from PA12 are highly resistant to chemicals, impact and UV light
- KR-ties up to 426 mm are made as one piece
- For assembly a special KR-tool is needed
Certifications & Approvals
Application
This cable tie is distinguished by its smooth strap and unique locking mechanism. The chamfered head of the KR-Series allows for a firm fit around the bundled element. Due to its special design KR-Series cable ties can be used as a safety method to bundle any cable and to also secure bellows on steering racks, water hoses or vacuum lines. The endless strap version is fairly flexible and can be cut to any length required. Separate heads are available to fix the strap.
KR-Series, 1-Piece is suitable for following markets and industries
-
Wind Energy Sector
-
Rail Transportation Sector
-
Automotive Industry
-
Electronics Industry
-
Aerospace Industry
-
Defence Industry
More products in this product group
Cable Tie locked by glass fibre pin >| Application Tool | KR6/8, KR8PNSE |
| Colour | Natural (NA) |
| Fixation Method | Cable Tie |
| Identification Plate Position | none |
| Pack Content | 50pcs. |
| Package Quantity per | pcs. |
| PART DESCRIPTION | KR8/33-PA66HS-NA |
| Product Family | KR-Series, 1-Piece |
| Product Group | Cable Tie locked by glass fibre pin |
| Releasable Closure (Yes/No) | No |
| Tie Closure | fibreglass pin |
| Variant | No Serration |
|
|
|
| Bundle ∅ max. | 86.0mm |
| Bundle ∅ min. | 8.0mm |
| Cable Tie Head Height (Metric) | 7.7mm |
| Cable Tie Head Length (metric) | 8.2mm |
| Cable Tie Head Width (metric) | 11.8mm |
| Length (L) | 337.0mm |
| Min.Tensile Strength | 785.0N |
| Strap Width max. (G) | 0.46" |
| Thickness (T) | 2.3mm |
| Width (W) | 8.0mm |
| ELV compliant (Article 4 - 2) | YES |
| Flammability | UL 94 V2 |
| Hazardous good | No |
| Material | Polyamide 6.6, heat stabilised (PA66HS) |
| Material | PA66HS |
| Operating Temperature - °C | -40 °C to +105 °C |
| Specifications |
|
|
|
|
| EAN / GTIN | 4031026114217 |
| Packaging 1 - Height (m) | 0.04m |
| Packaging 1 - Length (m) | 0.485m |
| Packaging 1 - Qty | 50 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00291m³ |
| Packaging 1 - Weight (kg) | 0.253753kg |
| Packaging 1 - Width (m) | 0.15m |
| Packaging 3 - Height (m) | 0.184m |
| Packaging 3 - Length (m) | 0.58m |
| Packaging 3 - Qty | 1500 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.0406m³ |
| Packaging 3 - Weight (kg) | 8.21259kg |
| Packaging 3 - Width (m) | 0.38m |
| Packaging 4 - Height (m) | 1.249m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 36000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.199m³ |
| Packaging 4 - Weight (kg) | 218.28kg |
| Packaging 4 - Width (m) | 0.8m |
| Weight | 0.24kg |
| UNSPSC Key | 39121703 |
