Label, self laminating, white, dot-matrix print, 30.50mm, H2=57.20mm, 1008pcs.
Art.-No. 595-00003 | TAGN49-PET-WH

Made of Polyester(PET) film
White color

Add to watchlist

Request your individual offer now

Request quote

More products in this product group:

Label for dot printer >

Base Data

Application	Used in applications where low to medium print volumes are needed and where simple alphanumeric texts are required. The materials are ideally suited to the most demanding environments giving good initial tack and excellent adhesive properties. A range of colours is available to suit most needs. Because of the wide variety of materials, Helatag labels can be used in many applications. For example, Tedlar is especially suitable for use under extreme temperature conditions. Document film can ensure e.g. tamper-proof guarantee marking, since it can only be removed by destroying it. For problem-free printing, we recommend our easy to use windows based TagPrint Pro software program, which comes pre-loaded with all our standard label templates so you can start producing labels immediately. The labels are supplied in a protective box that ensures dirt and dust is kept away from your labels so ensuring less waste.
Cable ⌀ max	13.0mm
Colour	White (WH)
Material	Polyester (PET)
PART DESCRIPTION	TAGN49-PET-WH
Pack Content	1008pcs.
Package Content packed in	bag
Print Method	dot-matrix print
Product Family	TABTAG Label
Product Group	Label for dot printer
Type	TAGN49

Product Dimensions

H printable	15.20mm
Height (H2)	57.20mm
Outside ⌀ max (OD max.)	13.00mm
Thickness (T)	47.0µm
Width (W)	30.50mm
Width of Liner (WL)	230.00mm
Width of printable area	30.50mm

Downloads

Specifications

Adhesive	Acrylic
Operating Temperature	-40 °C to +120 °C
ROHS compliant	Yes
Specifications
Specifications	ANSI/UL 969
UL File link	Link
UL-File Number	MH29199

Logistics and Packaging

GTIN-13 / EAN	4944387940251
Labels per Column	6
Labels per Row	4
Labels per Sheet	24
