10/11/2025

BHMCC17TC-PA66HIRHSUV/POM/SpS-BK
Art.-Nr. 151-04526 | BHMCC17TC-PA66HIRHSUV/POM/SpS-BK |

Copied

    • Easy to install by simply pushing into place
    • Connection can be released (non-destructive)
    • One fit tree foot part can be used for a variety of panel thicknesses
    • Disc covers the hole to prevent dust and dirt gaining access
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement
    Colour Black (BK)
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV), Polyacetal (POM), Spring Steel (SpS)
    PART DESCRIPTION BHMCC17TC-PA66HIRHSUV/POM/SpS-BK
    Package Content 2500pcs.
    Package Content packed in box
    Type BHMCC17TC
    UV-Stabilised No
    Height (H) 21.7mm
    Length (L) 29.1mm
    Width (W) 16.75mm
    for Hole ⌀ (FH) 7.6 - 8.4 mm
    for Panel Thickness min - max 14
    CE Certification No
    CSA Certified No
    Halogen-free Yes
    Operating Temperature -40 °C to +90 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin MX
    GTIN-13 / EAN 4031026772608
    Packaging 3 - Height (m) 0.37465m
    Packaging 3 - Length (m) 0.59055m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0646m³
    Packaging 3 - Width (m) 0.2921m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 31162305
