22/07/2025

Bundling clip, L=36.25mm, SO=9.2mm, white, 4000pcs.
Art.-Nr. 133-03800 | TEC48-PA66HIRHS/MET-WH |

Copied
Tape clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes.

    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions.
    Colour Cream (CM)
    Fixation Method Edge Clip
    Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS), Metal (MET)
    PART DESCRIPTION TEC48-PA66HIRHS/MET-WH
    Package Content 4000pcs.
    Package Content packed in pack
    Product Family for panel thicknesses of 1.0 - 4.0 mm
    Product Group Bundling clips with edge clips
    Type TEC48
    UV-Stabilised No
    ⌀ D 0.16"
    Bundle ⌀ 7.8mm
    Bundle ⌀ max. 7.8mm
    Bundling Bar Length 36.25mm
    Diameter (D) 4.0mm
    Height (H) 7.5mm
    Length (L) 15.1mm
    Length (L2) 36.2mm
    Offset Length 9.2mm
    Panel Thickness max. 0.8 - 2.0mm
    Width (W) 9.9mm
    Width (W2) 15.1mm
    for Panel Thickness min - max 0.8 - 2 mm
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +105 °C
    ROHS compliant Yes
    Specifications
    UL Listed (US and Canada) No
    UL Listed (US and Canada) No
    UL Recognized (US and Canada) No
    UL Recognized (US) No
    Country of Origin MX
    GTIN-13 / EAN 4031026715018
    Packaging 1 - Type carton
    Packaging 3 - Height (m) 0.1730375m
    Packaging 3 - Length (m) 0.57785m
    Packaging 3 - Type box
    Packaging 3 - Volume (m³) 0.0349m³
    Packaging 3 - Weight (kg) 10.02kg
    Packaging 3 - Width (m) 0.34925m
    ETIM 7.0 Key EC000127
    ETIM 8.0 Key EC000127
    ETIM 9.0 Key EC000127
    UNSPSC Key 39121702
