Label, weather resistant/chemical resistance, white, thermal transfer print, 36.3x20.32mm, 5000pcs.

Art.-Nr. 596-28250

| TAG28T4-250-WH

|

Conformable to adhere to a wide variety of curved and compound surfaces.

Ideal for marking and identification of wires and cables
Clear self laminating film wraps around the cable to protect marks from dirst and abrasion
Excellent UV and temperature resistance
Ideal for both internal and external application

Add to watchlist

Request quote

Downloads

More products in this product group:

Adhesive Labels

Base Data

Application	The use of our specially formulated adhesive labels printed on thermal transfer printers give the highest quality print clarity. The range of materials are complemented by ribbons developed to suit the needs of most users. The production of labels is very simple. All that is needed is the required label to be selected from our industry leading software TagPrint Pro.
Colour	White (WH)
Colour Marking Field	White (WH)
Key product features	weather resistant, chemical resistance
Material	Type 250, Nylon fabric, white (250)
PART DESCRIPTION	TAG28T4-250-WH
Package Content	5000pcs.
Package Content packed in	pack
Print Method	thermal transfer print
Product Group	Adhesive Labels
Type	TAG28T4
UV-Stabilised	No

Product Dimensions

H printable	36.3mm
HR	0.8"
HR	20.3mm
Height (H)	36.3mm
Thickness (T)	64.0µm
VR	41.1mm
VR	1.62"
Width (W)	20.32mm
Width of LIner (WL)	3.45"
Width of Liner (WL)	87.63mm

Downloads

Specifications

Adhesive	Acrylic
Adhesive Operating Temperature	-40 °C to +120 °C
CE Certification	No
CSA Certified	No
Curing Temperature	+10 °C
Halogen-free	No
Operating Temperature	-40 °C to +120 °C
ROHS compliant	Yes
Specifications
UL Listed (US and Canada)	No
UL Listed (US)	No
UL Recognized (US and Canada)	No
UL Recognized (US)	No

Logistics and Packaging

Country of Origin	US
GTIN-13 / EAN	4031026175775
Labels per Column	1
Labels per Row	4
Packaging 1 - Qty	1
Packaging 1 - Type	pack
Packaging 1 - Weight (kg)	0.68kg
Packaging 2 - Qty	1
Packaging 3 - Qty	5000
Packaging 4 - Length (m)	1.20m
Packaging 4 - Type	pallet
Packaging 4 - Width (m)	0.80m

More Information

ETIM 7.0 Key	EC001530
ETIM 8.0 Key	EC001530
ETIM 9.0 Key	EC001530
UNSPSC Key	55121606
