Fixing tie for hole (round), Ø1.0-27.0mm, natural, 100pcs.
Art.-No. 115-00114 | RR30SWPM5-PA66-NA Details

  • Easy to assemble without the need for a tool
  • Cable tie head always situated in defined position
  • Arrowhead simply locks into place
  • Supporting legs provide a secure and firm fixing in areas where space is limited
  • Releasable and therefor reusable
Show more

Request your individual offer now

Application With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building.
Application Tool MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7SP, EVO7i, EVO7iSP
Colour Natural (NA)
Fixation Method arrowhead
Identification Plate Position none
Key product features releasable
Material Polyamide 6.6 (PA66)
Pack Content 100pcs.
Package Content packed in bag
PART DESCRIPTION RR30SWPM5-PA66-NA
Product Family for round holes, releasable
Product Group 1-piece fixing ties with arrowhead, with wings
Releasable Closure (Yes/No) Yes
Bundle Diameter max (metric) 27.0mm
Bundle ∅ min. 1.0mm
for Hole ∅ (FH) 4.8 - 5.1 mm
for Panel Thickness min - max 0.5 - 2.5 mm
Length (L) 134.0mm
Min.Tensile Strength 98N
Width (W) 3.3mm
Flammability UL 94 V2
Operating Temperature -40 °C to +85 °C
Specifications
Specifications ANSI/UL 1565, ANSI/UL 62275
UL OCD link Link
UL Recognized (US and Canada) Yes
UL-File Number E64962
GTIN-13 / EAN 4944387107104
UNSPSC Key 39121703
