31/10/2025

Fixing tie for cable bundles, inside serrated, ⌀10.0-105.0mm, grey, 250pcs.
Art.-Nr. 156-02416 | T120RCOUPLER-PA46-GY |

Copied
T50RCOUPLER for parallel routing.
T-Series with Coupler
Cable Ties with Coupler
Coupler

    • Pre-assembled 2-piece fixing tie with coupler
    • Cable tie head can be moved after bundling
    • Easy addition of cables after assembly
    • For parallel routing of bundles that can be twisted 90° even after installation
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Colour Grey (GY)
    Description The Coupler is the simple way to connect two cable ties for a parallel routing of two bundles. His special design allows the ties 90 degrees of rotation. This is ideal for all applications where the cable, pipe or hose should move flexible in relation to the fixing point. The Coupler can be used with one or two cable ties. This allows easily subsequent installation or replacements of further cables, pipes or hose.
    Identification Plate Position none
    Key product features for multiple routing
    Material Polyamide 4.6 (PA46)
    Min.Tensile Strength 535N
    PART DESCRIPTION T120RCOUPLER-PA46-GY
    Package Content 250pcs.
    Package Content packed in bag
    Product Family twistable up to 90°
    Product Group 2-piece fixing ties for parallel separation
    Tie Closure plastic pawl
    Type T120RCOUPLER
    Variant Inside Serrated
    ⌀ max. 1. loop 100.0mm
    ⌀ max. 2. loops 100.0mm
    Bundle ⌀ 10.0-105.0mm
    Bundle ⌀ max. 105.0mm
    Bundle ⌀ min. 10.0mm
    Length (L) 390mm
    Strap Width max. (G) 0.3
    Strap Width max. (G) 7.6mm
    Width (W) 7.6mm
    Hazardous Goods No
    ROHS compliant Yes
    Specifications
    Country of Origin FR
    Customs Number 39269097
    GTIN-13 / EAN 4031026602868
    Packaging 1 - Length (m) 0.600m
    Packaging 1 - Qty 250
    Packaging 1 - Width (m) 0.500m
    Packaging 3 - Height (m) 0.250m
    Packaging 3 - Length (m) 0.600m
    Packaging 3 - Qty 1000
    Packaging 3 - Volume (m³) 0.06m³
    Packaging 3 - Width (m) 0.400m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
