Fixing tie for hole (round), outside serrated, ⌀2.0-50.0mm, black, 1000pcs.
Art.-Nr. 157-00216
| T50ROSFT612.5SO-PA66HIRHSUV-BK
|
Copied
- Bundling and fixing solution
- Ideal combination of materials and design
- Different positions of the fixing anchor are available to fit installation space
Request quote
More products in this product group:
1-piece fixing ties with fir tree, with disc, with stand-off, for round holes
| Colour | Black (BK) |
| Ergonomy Feature |
≤ 30 N assembly force: Product fulfills defined assembly force requirements. Details and tolerances as per technical drawing. Actual force may vary depending on the surface, assembly situation and accessibility. Verify applicability under real conditions before use to ensure applicability for the intended purpose. |
| Fixation Method | Fir tree for round holes |
| Identification Plate Position | none |
| Key product features | ergonomic design |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| Min.Tensile Strength | 220N |
| PART DESCRIPTION | T50ROSFT612.5SO-PA66HIRHSUV-BK |
| Package Content | 1000pcs. |
| Package Content packed in | pack |
| Product Family | With offset 12.5 mm |
| Product Group | 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes |
| Releasable Closure (Yes/No) | No |
| Short Description | 1-Piece Fixing Ties with Fir Tree and Disc, with Stand-off, for Round Holes |
| Type | T50ROSFT612.5SO |
| UV-Stabilised | Yes |
| Weight/Unit | 0.002194kg |
| Bundle ⌀ | 2.0-50.0mm |
| Bundle ⌀ max. | 50.0mm |
| Bundle ⌀ min. | 2.0mm |
| Disc ⌀ | 16.6mm |
| Height (H) | 16.1mm |
| Hole Depth | 0.6mm |
| Hole Depth | 6.0mm |
| Length (L) | 234.2mm |
| Length (L2) | 12.5mm |
| Offset Length | 12.5mm |
| Panel Thickness | 0.6 - 6.0mm |
| Thickness (T) | 1.5mm |
| Width (W) | 5.1mm |
| for Hole ⌀ (FH) | 6.1 - 6.9 mm |
| for Panel Thickness min - max | 0.6 - 6 mm |
| for Panel Thickness min - max | 0 - 0.2 " |
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | Yes |
| Flammability | UL 94 HB |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| Operating Temperature, 1000h | +160 °C |
| Operating Temperature, 5000h | +125 °C |
| Operating Temperature, 500h | +165 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
|
|
|
| Country of Origin | US |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026494470 |
| Packaging 1 - Height (m) | 0.1m |
| Packaging 1 - Length (m) | 0.7m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.02835m³ |
| Packaging 1 - Weight (kg) | 2.244kg |
| Packaging 1 - Width (m) | 0.405m |
| Packaging 3 - Height (m) | 0.37465m |
| Packaging 3 - Length (m) | 0.59055m |
| Packaging 3 - Qty | 3000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0646m³ |
| Packaging 3 - Weight (kg) | 7.477kg |
| Packaging 3 - Width (m) | 0.2921m |
| Packaging 4 - Height (m) | 1.254m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 36000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.204m³ |
| Packaging 4 - Weight (kg) | 111.724kg |
| Packaging 4 - Width (m) | 0.8m |
