Fixing tie for hole (round), Ø2.0-50.0mm, black, 3000pcs.
Art.-Nr. 157-00516 | T50ROSFTM6SO25B-PA66HIRHSUV-BK |  Details

The fir tree mount cable tie is an all-in-one bundling and fastening solution that reduces costs and assembly time.

    • Bundling and fixing solution
    • Ideal combination of materials and design
    • Different positions of the fixing anchor are available to fit installation space
    Package size
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Tool ProCut 9 no battery, MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP, EVO9, EVO9SP, EVO9i, EVO9iSP
    Colour Black (BK)
    Fixation Method Fir tree for round holes
    Identification Plate Position none
    Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
    Pack Cont. 3000pcs.
    Package Content packed in carton
    PART DESCRIPTION T50ROSFTM6SO25B-PA66HIRHSUV-BK
    Product Family With offset 12.5 and 25.0 mm
    Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes
    Releasable Closure (Yes/No) No
    Short Description 1-Piece Fixing Ties with Fir Tree and Disc, with Stand-off, for Round Holes
    Bundle Diameter max (metric) 50.0mm
    Bundle ∅ 2.0-50.0mm
    Bundle ∅ min. 2.0mm
    Disc ∅ 19.0mm
    for Hole ∅ (FH) M6
    for Panel Thickness min - max 0.6 - 5.5 mm
    for Panel Thickness min - max 0 - 0.2 "
    Height (H) 21.8mm
    Length (L) 230.0mm
    Length (L2) 25.0mm
    Min.Tensile Strength 222.4N
    Offset Length 25.0mm
    Panel Thickness max. 0.6 - 5.5mm
    Width (W) 4.6mm
    CE Certification No
    CSA Certified No
    Operating Temperature -40 °C to +105 °C
    Specifications
    UL Recognized (US and Canada) No
    UV-Stabilised Yes
    Country of Origin US
    GTIN-13 / EAN 4031026657707
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
    Show all
    Show all
    Cable holder Cable holder

    Cable holder

    Looking for a secure way to fasten cables or wires? Our plastic cable holders are easy to install and suitable for almost any application. Learn more...

    Cable holder >
