GR 50-150-PO-X-BK


Art.-No. 323-00001

| GR 50-150-PO-X-BK

 |

Copied
Colour Black (BK)
Material Polyolefin, cross-linked (PO-X)
PART DESCRIPTION GR 50-150-PO-X-BK
Pack Content 10m
Package Content packed in reel
Printable No
Shrink Ratio up to 4:1
Type GR 50-150
Variant Medium-Wall
With inner glue (Yes/No) No
For Object Outside Diameter 9.4-19.6 mm
Length (L) 10mm
Longitudinal Change After Shrinkage -10% max.
Recov. ⌀ d max. 6.0mm
Supplied ⌀ D min. 23.0mm
Wall (WT) 2.00mm
Dielectric Strength 15kV/mm
Halogen-free Yes
Min. Shrink Temperature - °C +135 °C
Operating Temperature -55 °C to +130 °C
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026668246
UNSPSC Key 39121723
