Fixing tie for hole (round), Ø6.5-6.5mm, black, 100pcs.
Art.-No. 115-00092 | RR30-110-7.6-PA66-BK Details

This product is not available anymore.
  • Easy to assemble without the need for a tool
  • Cable tie head always situated in defined position
  • Arrowhead simply locks into place
  • Supporting legs provide a secure and firm fixing in areas where space is limited
  • Releasable and therefor reusable
Show more

Request your individual offer now

Application With a diverse range of fixing possibilities are ideal for use in many different industries, including automotive, aerospace and panel building.
Application Tool EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9SP, EVO9HT
Colour Black (BK)
Fixation Method arrowhead
Identification Plate Position none
Key product features releasable
Material Polyamide 6.6 (PA66)
Pack Content 100pcs.
Package Content packed in bag
PART DESCRIPTION RR30-110-7.6-PA66-BK
Product Family for round holes, releasable
Product Group 1-piece fixing ties with arrowhead, with wings
Releasable Closure (Yes/No) Yes
Bundle Diameter max (metric) 6.5mm
Bundle ∅ min. 6.5mm
for Hole ∅ (FH) 4.9 - 5.1 mm
for Panel Thickness min - max - 2.5
Height (H2) 9.25mm
Length (L) 110mm
Length (L2) 18.3mm
Min.Tensile Strength 135N
Thickness (T) 1.2mm
Width (W) 5mm
Width (W2) 4.6mm
Width (W3) 15mm
Flammability UL 94 V2
Operating Temperature -40 °C to +85 °C
Specifications
GTIN-13 / EAN 4944387955972
UNSPSC Key 39121703
