Fixing tie for hole (round), Ø1.5-45.0mm, black, 500pcs.
Art.-Nr. 156-03279 | T50RFT8GSD-PA66W-BK |  Details

Fxing Tie for 8.0 - 8.5 mm round holes.

    • Pre-assembled 2-piece fixing tie with fir tree foot part
    • Cable tie head can be moved after bundling
    • Easy to assemble without the need for a tool
    • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
    • Fir tree foot part can be used for a variety of panel thicknesses
    • Suitable for use within threaded holes
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.
    Application Tool ProCut 9 no battery, MK3PNSP2, EVOcut, MK7P, MK10-SB, MK20, EVO7, EVO7SP, EVO7i, EVO7iSP, EVO9, EVO9SP, EVO9i, EVO9iSP
    Cable Tie Polyamide 6.6, UV-resistant (PA66W)
    Colour Black (BK)
    Fixation Method Fir Tree
    Foot Part Polyamide 6.6, UV-resistant (PA66W)
    Identification Plate Position none
    Material Polyamide 6.6, UV-resistant (PA66W)
    Pack Cont. 500pcs.
    Package Content packed in bag
    PART DESCRIPTION T50RFT8GSD-PA66W-BK
    Product Family Fir tree parts FT8
    Product Group 2-piece fixing ties with fir tree, with disc, for round holes
    Tie Closure plastic pawl
    Variant Inside Serrated
    Bundle Diameter max (metric) 45.0mm
    Bundle ∅ 1.5-45.0mm
    Bundle ∅ min. 1.5mm
    Disc ∅ 16.0
    for Hole ∅ (FH) 8.0 - 8.5 mm
    for Panel Thickness min - max 1.5 - 4 mm
    Length (L) 202mm
    Min.Tensile Strength 225N
    Thickness (T) 1.2mm
    Weight/Unit 0.0021kg
    Width (W) 4.6mm
    Specifications
    Country of Origin FR
    GTIN-13 / EAN 4031026733425
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    Packaging 2 - Qty 3000
    Packaging 2 - Type carton
    Packaging 4 - Height (m) 1.225m
    Packaging 4 - Length (m) 1.20m
    Packaging 4 - Qty 36000
    Packaging 4 - Type pallet
    Packaging 4 - Volume (m³) 1.176m³
    Packaging 4 - Width (m) 0.80m
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121717
