Releasable cable tie, 300x4.6mm, Ø5.0-81.0mm, 200N, natural, 100pcs.
Art.-No. 115-02101 | RELK2I-PA66-NA Details

  • Releasable and reusable cable tie
  • Available in black and natural colour
  • Extended trigger for simple and quick release of ties
  • RELK cable ties are inside serrated
  • Different lengths are available
Show more

Request your individual offer now

Application Used in a wide range of industries these releasable and reusable ties are ideal where changes are anticipated. This includes temporary installation and the addition or removal of elements. These releasable cable ties are commonly used to fix stage equipment, for cable management at outdoor events or prototype harnessing work. The extended pawl is simply pushed down with a finger to release the strap.
Colour Natural (NA)
Fixation Method Releasable Cable Tie
Identification Plate Position none
Key product features releasable
Material Polyamide 6.6 (PA66)
Pack Content 100pcs.
Package Content packed in bag
PART DESCRIPTION RELK2I-PA66-NA
Product Family RELK-Series up to 200 N loop tensile strength
Product Group Cable ties inside serrated
Releasable Closure (Yes/No) Yes
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 81.0mm
Bundle ∅ min. 5.0mm
Length (L) 300mm
Min.Tensile Strength 200N
Thickness (T) 1.5mm
Width (W) 4.6mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2
Halogen-free Yes
Hazardous Goods No
Operating Temperature -40 °C to +85 °C
Specifications
Specifications IEC 60092 series
GTIN-13 / EAN 5022660315404
Packaging 1 - Height (m) 0.04m
Packaging 1 - Length (m) 0.406m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00247
Packaging 1 - Weight (kg) 0.120001kg
Packaging 1 - Width (m) 0.152m
Packaging 3 - Height (m) 0.192m
Packaging 3 - Length (m) 0.586m
Packaging 3 - Qty 5000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0439
Packaging 3 - Weight (kg) 6.802kg
Packaging 3 - Width (m) 0.39m
Packaging 4 - Height (m) 1.164m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 100000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.117
Packaging 4 - Weight (kg) 157.04kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121703
