Cable clip, T=0.7 - 3.0mm, ∅4.5 - 5.0 mm, Dmin=4.3mm, Dmax=5.2mm
Art.-No. 151-01405 | HC48FT5-PA66HIRHS-BK Details

Request your individual offer now

Application This Fixing Element is pressed into a hole by hand and locked into place with a hearable click. Cable bundles can be applicated afterwards.
Cable ∅ max 5.2mm
Cable ∅ min 4.3mm
Colour Black (BK)
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
PART DESCRIPTION HC48FT5-PA66HIRHS-BK
Pack Content 5000pcs.
Package Content packed in bag
Product Family With Fir Tree
Product Group Fixing Elements for Tubes and Harnesses
Type HC48FT5
Attach to Ø 4.3 - 5.2
Bundle Diameter max (metric) 5.2mm
Bundle ∅ min. 4.3mm
Height (H) 21.0mm
Panel Thickness max. 0.7 - 3.0mm
for Hole ∅ (FH) 4.5 - 5.0 mm
for Panel Thickness min - max 0.7 - 3 mm
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
ROHS compliant Yes
Specifications
GTIN-13 / EAN 4031026535173
Packaging 3 - Height (m) 0.3m
Packaging 3 - Length (m) 0.4m
Packaging 3 - Qty 5000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.036
Packaging 3 - Weight (kg) 6.995kg
Packaging 3 - Width (m) 0.3m
Packaging 4 - Height (m) 1.044m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 120000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.002
Packaging 4 - Weight (kg) 188.88kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121702
