21/05/2025

End Caps
Art.-No. 924-00262 | HSEC120-PO-X-BK |

Copied
The appropriate end cap for every cable diameter and cable types.

    • Seal cables during storage or transportation
    • Insulating cap for live LV cables (0.6/1 kV)
    • Adhesive lining for excellent environmental seal
    • High shrink ratio to minimise number of sizes needed
    • UV Resistant
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application End caps are suitable for use on aluminium or steel armoured cables.
    Bestell Typ HSEC120
    Bezeichnung HEATSHRINK ADHESIVE END CAP 25/8.5MM LENGTH 75MM
    Farbe Black (BK)
    Inhalt 1ST
    Inhalt per pcs.
    Material Polyolefin, cross-linked (PO-X)
    Produktbezeichnung HSEC120-PO-X-BK
    Produktfamilie Helashrink HSEC, low voltage with adhesive coating
    Produktgruppe End Caps
    Schrumpfrate up to 3:1
    Typ HSEC120
    ⌀H max. b 8.5mm
    ⌀H min. a 25mm
    HW ± 20% 2.5mm
    Länge (L) 75mm
    P ± 10% 75mm
    Betriebstemperatur -55 °C to +110 °C
    Brandschutzeigenschaften ASTM D2671
    Durchschlagsfestigkeit 12kV/mm
    Min. Schrumpftemperatur +135 °C
    ROHS konform Yes
    Zulassungen/Normen
    EAN / GTIN 9349519008512
    Ursprungsland CN
    Zollwarentarif Nr. 39174000
    Heat shrink tubing Heat shrink tubing

    Heat shrink tubing

    You are looking for the heat shrink tubing meeting your application requirements best? The key factors to which we owe our success are the unique and quite specific properties of our heat shrink tubing.

    Heat shrink tubing >
