Cable tie inside serrated detectable, 387.0x7.6mm, ⌀3.0-100.0mm, blue, 100pcs.
Art.-No. 111-01136 | MCT120R-PA66MD-BU |

Copied

    • Total metal dispersion throughout the tie
    • Can support quality assurance in the production of food stuffs, for example HACCP
    • Blue colour for easy visual detection
    • Greatly reduces risk of contamination
    • Magnetic detectable (detection level depending on specific application and equipment)
    Show more
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application The Metal Content Tie is a cable tie specifically designed for use in the food and pharmaceutical processing industries. A unique manufacturing process, involving the inclusion of a metallic pigment, enables even small 'cut-off' sections of the tie to be detected by standard metal-detecting equipment. Ideally suited for the installaton of cabling in and around the manufacturing process.
    Ausführung Inside Serrated
    Bandverschluss plastic pawl
    Befestigungsart Cable Tie
    Besonderheiten detectable
    Bestell Typ MCT120RBU
    Farbe Blue (BU)
    Inhalt 100ST
    Inhalt per pack
    Kurzbeschreibung Metal Content Tie 387x7.6 mm, PA66MP, blue
    Lösbarer Verschluss No
    Material Polyamide 6.6, metal detectable (PA66MD)
    Position Beschriftungsfläche none
    Produktbezeichnung MCT120R-PA66MD-BU
    Produktfamilie MCT-Series, PA66MP
    Produktgruppe Cable ties for food industry, detectable
    Typ MCT120R
    Breite (W) 7.6mm
    Bündel ⌀ 3.0-100.0mm
    Bündel ⌀ max. 100.0mm
    Bündel ⌀ min. 3.0mm
    Dicke (T) 1.8mm
    Länge (L) 387.0mm
    Mindesthaltekraft 535N
    Teil - Nettogewicht 0.00282kg
    Betriebstemperatur -40 °C to +85 °C
    Brandschutzeigenschaften UL 94 HB
    CE konform Yes
    ELV konform YES
    Gefahrgut No
    Halogenfrei Yes
    ROHS konform Yes
    UL Listung No
    UL Listung (gültig in USA) No
    UL anerkannt No
    UL anerkannt (gültig in USA) No
    UV-beständig No
    Zertifiziert nach CSA No
    Zulassungen/Normen
    EAN / GTIN 5022660333118
    Ursprungsland GB
    Verpackung 1 - Beschaffenheit bag
    Verpackung 1 - Breite, gefüllt (m) 0.179m
    Verpackung 1 - Gewicht (kg) 0.630001kg
    Verpackung 1 - Höhe (m) 0.053m
    Verpackung 1 - Länge (m) 0.429m
    Verpackung 1 - Menge 100
    Verpackung 1 - Volumen (m³) 0.004069923m³
    Verpackung 3 - Beschaffenheit box
    Verpackung 3 - Breite (m) 0.39m
    Verpackung 3 - Gewicht (kg) 13.402kg
    Verpackung 3 - Höhe (m) 0.192m
    Verpackung 3 - Länge (m) 0.586m
    Verpackung 3 - Menge 2000
    Verpackung 3 - Volumen (m³) 0.0439m³
    Verpackung 4 - Beschaffenheit pallet
    Verpackung 4 - Breite (m) 0.8m
    Verpackung 4 - Gewicht (kg) 289.04kg
    Verpackung 4 - Höhe (m) 1.235m
    Verpackung 4 - Länge (m) 1.2m
    Verpackung 4 - Menge 40000
    Verpackung 4 - Volumen (m³) 1.186m³
    ETIM 7.0 EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Code 39121703
