Corrugated tube clip for hole (round), nom⌀4.5mm, black, 500pcs.
Art.-No. 151-14314
| CTC4.5FT6LG-PA66HIRHS-BK
|
Copied
- CTC clamps for a variety of nominal diameters
- Fir tree foot part can be used for a variety of panel thicknesses
- Suitable for use within threaded holes
- Tube is guided accurately by clicking
- Axial slipping is prevented by the inside profile of the clamp
Request your individual offer now
Request quote
More products in this product group:
| Application | CTC clamps are used for example in the automotive, harness making, electrical industry and wherever corrugated tubing has to be quickly and firmly fixed. |
| ⌀ | IWS 4,5 |
| Befestigungsart | Fir Tree |
| Besonderheiten | for convoluted tubes or with rib, reusable, removable |
| Bestell Typ | CTC4.5FT6LG |
| Farbe | Black (BK) |
| Inhalt | 500ST |
| Inhalt per | pack |
| Kurzbeschreibung | Fixing Elements with Fir Tree for Corrugated Tubing black |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| Produktbezeichnung | CTC4.5FT6LG-PA66HIRHS-BK |
| Produktfamilie | CTC-Series |
| Produktgruppe | Fixing elements for corrugated tubing, with fir tree |
| Typ | CTC4.5FT6LG |
Download
|
|
|
| EAN / GTIN | 4031026237817 |
| Ursprungsland | FR |
| Verpackung 1 - Beschaffenheit | bag |
| Verpackung 1 - Breite, gefüllt (m) | 0.44m |
| Verpackung 1 - Gewicht (kg) | 0.503478kg |
| Verpackung 1 - Höhe (m) | 0.3m |
| Verpackung 1 - Länge (m) | 0.625m |
| Verpackung 1 - Menge | 500 |
| Verpackung 1 - Volumen (m³) | 0.0825m³ |
| Verpackung 3 - Beschaffenheit | box |
| Verpackung 3 - Breite (m) | 0.386m |
| Verpackung 3 - Gewicht (kg) | 12.903472kg |
| Verpackung 3 - Höhe (m) | 0.368m |
| Verpackung 3 - Länge (m) | 0.584m |
| Verpackung 3 - Menge | 12000 |
| Verpackung 3 - Volumen (m³) | 0.083m³ |
| Verpackung 4 - Beschaffenheit | pallet |
| Verpackung 4 - Breite (m) | 0.8m |
| Verpackung 4 - Gewicht (kg) | 175.704kg |
| Verpackung 4 - Höhe (m) | 1.249m |
| Verpackung 4 - Länge (m) | 1.2m |
| Verpackung 4 - Menge | 144000 |
| Verpackung 4 - Volumen (m³) | 1.199m³ |
