Cable tie mount for screw fixation, Wmax=6.4mm, ⌀4.5 mm, M4 Screw, blue, 100pcs.
Артикулен 151-00653
| KR6G5-E/TFE-BU
|
Copied
- Curved design for additional cable support
- Simple to install with a screw or bolt
- Excellent security, particularly in areas of high vibration
- Mounts are available in various sizes and materials
Оферта
Още продукти от тази продуктова група:
| Colour | Blue (BU) |
| Fixation Method | Screw Mounting and Rivet |
| Material | Ethylene Tetrafluoroethylene (E/TFE) |
| Mounting Screw Type | M4 Screw |
| PART DESCRIPTION | KR6G5-E/TFE-BU |
| Package Content | 100pcs. |
| Package Content packed in | bag |
| Product Family | KR-E/TFE for a broad temperature range |
| Product Group | Screw fixing mounts |
| Short Description | Screw Fixing Mount for a broad temperature range |
| Strap Thickness max. | 2.4 |
| Type | KR6G5 |
| Typical Application | Designed specifically for holding heavier cable bundles these mounting bases can be used in many industries from Agriculture to Truck manufacture, they offer a very secure fixing and can be used with a wide variety of heavy duty cable ties up to 7.6 mm wide. |
| UV-Stabilised | Yes |
| Weight/Unit | 0.00088kg |
| ELV compliant (Article 4 - 2) | Yes |
| Flammability | UL 94 V0 |
| Hazardous Goods | No |
| Operating Temperature | -80 °C to +170 °C |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | ANSI/UL 1565, ANSI/UL 62275 |
| UL File link | Връзка |
| UL Recognized (US) | Yes |
| UL-File Number | E64962 |
|
|
|
| Country of Origin | JP |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4944387953176 |
| Packaging 1 - Height (m) | 0.025m |
| Packaging 1 - Length (m) | 0.2m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.00065m³ |
| Packaging 1 - Weight (kg) | 0.088001kg |
| Packaging 1 - Width (m) | 0.13m |
| Packaging 3 - Height (m) | 0.28m |
| Packaging 3 - Length (m) | 0.45m |
| Packaging 3 - Qty | 10000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0391m³ |
| Packaging 3 - Weight (kg) | 9.1401kg |
| Packaging 3 - Width (m) | 0.31m |
| Packaging 4 - Height (m) | 0.984m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 120000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 0.945m³ |
| Packaging 4 - Weight (kg) | 131.68kg |
| Packaging 4 - Width (m) | 0.8m |
