Bundling clip for edge, L=50.0mm, SO=65.0mm, black, 500pcs.
Артикулен 151-00022
| EC30-PA66HIRHS-BK
|
Copied
- Especially for banding of cables and cable harnesses
- Fastened onto bundling bar with cable ties or adhesive tape
- Various base geometries for different routing directions avaliable
- Integrated double tempered steel spring clamp holds clip firmly in place
- Ideal for applications where holes or adhesives are not suitable

Заявете вашата индивидуална оферта сега
Оферта
Още продукти от тази продуктова група:
Application | Bundling clips are designed to provide simple and easy methods of securing cable bundles, hoses, or pipes. They are fastened onto the tape bar using bundle or cable ties. The different fixing orientations allow tape clips to be used with a wide range of panel thicknesses and hole diameters. Standard bundling clips are available as well as standoff and stud mount versions. |
Colour | Black (BK) |
Fixation Method | Edge Clip |
Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
PART DESCRIPTION | EC30-PA66HIRHS-BK |
Pack Cont. | 500pcs. |
Package Content packed in | bag |
Product Family | Bundling Clips for Edges, 1.0 - 3.0 mm, for Distance Routing |
Product Group | Bundling Clips for Edges for Distance Routing |
Short Description | Bundling Clip, edge, high impact modified, heat stabilised, black |
Type | EC30 |
Wings on clip base (Yes / No) | YES |
|
|
Country of Origin | DE |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026250281 |
Packaging 1 - Height (m) | 0.075m |
Packaging 1 - Length (m) | 0.385m |
Packaging 1 - Qty | 500 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.00952875m³ |
Packaging 1 - Weight (kg) | 1.572635kg |
Packaging 1 - Width (m) | 0.33m |
Packaging 3 - Height (m) | 0.368m |
Packaging 3 - Length (m) | 0.584m |
Packaging 3 - Qty | 4000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.083m³ |
Packaging 3 - Weight (kg) | 13.40108kg |
Packaging 3 - Width (m) | 0.386m |
Packaging 4 - Height (m) | 1.248m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 48000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.198m³ |
Packaging 4 - Weight (kg) | 181.8kg |
Packaging 4 - Width (m) | 0.8m |
