08/10/2024

Cable clip for adhesive use, Dmax=6.0mm
Art.-No. 151-01635 | RA6APT-I-PA66-NA Details

  • One-piece self adhesive mount for quick and easy installation
  • Can be used without cable ties offering process optimization
  • Designed to hold wires, cables or hoses
  • Different sizes for various bundle diameters available
  • Two types of adhesive can be offered
Show more

Request your individual offer now

Application These mounts are ideal for use in applications which are difficult to access or for areas where self adhesive is the only possible fixing method and fixing holes would be unacceptable. The self adhesive mounts can be used without cable ties. Offering process optimization in industries like automotive, bus and truck, construction vehicles or industrial building.
Colour Natural (NA)
Fixation Method Pasting / Stick
Material Polyamide 6.6 (PA66)
PART DESCRIPTION RA6APT-I-PA66-NA
Pack Content 100pcs.
Package Content packed in bag
Product Family RA-Series
Product Group Mounts with cable clip, self-adhesive
Type RA6APT-I
Variant Closed
Bundle Diameter max (metric) 6.0mm
Height (H) 9.0mm
Length (L) 19.0mm
Nominal ∅ 6.0mm
Width (W) 19.0mm
Width (W2) 5.0mm
Adhesive Acrylate with base of acrylic foam
Adhesive Operating Temperature -35 °C to +120 °C
ELV compliant (Article 4 - 2) YES
Flammability UL 94 V2 (excluding adhesive)
Hazardous Goods No
Operating Temperature -40 °C to +85 °C
ROHS compliant Yes
Specifications
UV-Stabilised No
GTIN-13 / EAN 4031026565866
Packaging 1 - Height (m) 0.1m
Packaging 1 - Length (m) 0.22m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00528
Packaging 1 - Weight (kg) 0.13658kg
Packaging 1 - Width (m) 0.24m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 8000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 11.7464kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.249m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 96000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.199
Packaging 4 - Weight (kg) 161.976kg
Packaging 4 - Width (m) 0.8m
UNSPSC Key 39121702
