Cable tie inside serrated for multiple routing, 210x4.7mm, ⌀1.6-38.0mm, grey, 100pcs.
Артикулен 117-05168
| T50RDH-PA46-GY
|
Copied
- Possibility to separate bundles with only one cable tie
- Cable tie with two heads creating an inside and outside serrated loop
- Available in a wide range of materials
- Bundles can be of different diameter
- Maximum bundle diameter is a maximum combined bundle
- Easy application either manually or with a processing tool
покажи повече
Покажи по-малко
Оферта
Още продукти от тази продуктова група:
Този продукт е част от:
| Application |
Ideal for running two cables in parallel that need to be separated. These ties allow for installation of a second cable run without the need for additional cable ties. |
| Colour | Grey (GY) |
| Identification Plate Position | none |
| Key product features | for multiple routing |
| Material | Polyamide 4.6 (PA46) |
| Min. Tensile Strength 2nd loop | 180N |
| Min.Tensile Strength | 225N |
| PART DESCRIPTION | T50RDH-PA46-GY |
| Package Content | 100pcs. |
| Package Content packed in | pcs. |
| Product Family | DH-Series |
| Product Group | Cable ties for parallel routing |
| Releasable Closure (Yes/No) | No |
| Short Description | Two Head Cable Tie 210x4.7 mm PA46 |
| Tie Closure | plastic pawl |
| Type | T50RDH |
| Variant | Inside Serrated |
| Weight/Unit | 0.0017kg |
|
|
|
| Country of Origin | GB |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 5022660324390 |
| Packaging 1 - Height (m) | 0.035m |
| Packaging 1 - Length (m) | 0.305m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0016226m³ |
| Packaging 1 - Weight (kg) | 0.170001kg |
| Packaging 1 - Width (m) | 0.152m |
| Packaging 3 - Height (m) | 0.192m |
| Packaging 3 - Length (m) | 0.586m |
| Packaging 3 - Qty | 6000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0439m³ |
| Packaging 3 - Weight (kg) | 10.93006kg |
| Packaging 3 - Width (m) | 0.39m |
| Packaging 4 - Height (m) | 1.144m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 120000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.098m³ |
| Packaging 4 - Weight (kg) | 240.6kg |
| Packaging 4 - Width (m) | 0.8m |
