Fixing tie for hole (square), outside serrated, Ø1.6-25.0mm, natural, 500pcs.
Артикулен 126-00269 | OS150-PM712S-WPJ-PA66-NA Подробности

  • Bundling and fixing solution
  • Ideal combination of materials and design
  • Different positions of the fixing anchor are available to fit installation space

Заявете вашата индивидуална оферта сега

Application Tool EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO9SP, EVO9HT
Colour Natural (NA)
Fixation Method 1 piece
Identification Plate Position none
Material Polyamide 6.6 (PA66)
Pack Cont. 500pcs.
Package Content packed in bag
PART DESCRIPTION OS150-PM712S-WPJ-PA66-NA
Releasable Closure (Yes/No) No
Bundle Diameter max (metric) 25.0mm
Bundle ∅ 1.6-25.0mm
Bundle ∅ min. 1.6mm
Disc ∅ 17,5 x 22,5mm
for Hole ∅ (FH) 7.0 x 12.0 mm
for Panel Thickness min - max 0.5 - 1.2 mm
Length (L) 150.0mm
Min.Tensile Strength 150N
Width (W) 6.0mm
Operating Temperature -40 °C to +85 °C, (+105 °C, 500 h)
Specifications
Country of Origin CN
GTIN-13 / EAN 4031026542430
Packaging 3 - Weight (kg) 6.56kg
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
