Cable clip for hole (round), Ø6.3 - 6.7 mm, black, 2500pcs.
Артикулен 151-01843 | KSFT6.5OC1-3-PA66HIRHS-BK Подробности

  • Fixing part with rounded arrowhead to minimise assembly height
  • Ideal for applications where space is limited
  • Simply clip on a wire or hose
  • Bundle diameter is defined
  • Suitable for post-installation of bundles
покажи повече

Заявете вашата индивидуална оферта сега

Application This fixing elements can be used ideally everywhere where space saving work is necessary. In case of maintenance, the tubes and harnesses can be exchanged.
Colour Black (BK)
Fixation Method arrowhead
Key product features for narrow space, for narrow bundling, reusable
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Pack Cont. 2500pcs.
Package Content packed in bag
PART DESCRIPTION KSFT6.5OC1-3-PA66HIRHS-BK
Product Family KSFT6.5OC1-3 with arrowhead for bundle diameter 1.0 - 3.0 mm
Product Group Fixing elements for tubes and harnesses
Short Description Harness Clip, open, round hole 6.3 - 6.7 mm, arrow head, high impact modified, heat stabilised, black
Attach to Ø 1.0 - 3.0 mm
for Hole ∅ (FH) 6.3 - 6.7 mm
for Panel Thickness min - max 2.3 - 2.7 mm
Height (H) 14.4mm
Weight/Unit 0.000639kg
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026573779
Packaging 1 - Height (m) 0.15m
Packaging 1 - Length (m) 0.4m
Packaging 1 - Qty 2500
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.018
Packaging 1 - Weight (kg) 1.619493kg
Packaging 1 - Width (m) 0.3m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 20000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 13.775944kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 240000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 186.312kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000127
ETIM 8.0 Key EC000127
ETIM 9.0 Key EC000127
UNSPSC Key 39121702
