Fixing tie for hole (round), outside serrated, Ø2.0-50.0mm, black, 1000pcs.
Nr. articol 157-00217 | T50ROSFT812.5SO-PA66HIRHSUV-BK Detalii

  • Bundling and fixing solution
  • Ideal combination of materials and design
  • Different positions of the fixing anchor are available to fit installation space

Solicitați acum oferta dumneavoastră individuală

Application Tool EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO7, EVO7SP, EVO9, EVO9SP, EVO9HT
Colour Black (BK)
Fixation Method Fir tree for round holes
Identification Plate Position none
Material Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV)
Pack Cont. 1000pcs.
Package Content packed in carton
PART DESCRIPTION T50ROSFT812.5SO-PA66HIRHSUV-BK
Product Family With offset 12.5 and 25.0 mm
Product Group 1-piece fixing ties with fir tree, with disc, with stand-off, for round holes
Releasable Closure (Yes/No) No
Short Description 1-Piece Fixing Ties with Fir Tree and Disc, with Stand-off, for Round Holes
Bundle Diameter max (metric) 50.0mm
Bundle ∅ 2.0-50.0mm
Bundle ∅ min. 2.0mm
Disc ∅ 19.0mm
for Hole ∅ (FH) 7.6 - 8.4 mm
for Panel Thickness min - max 0.6 - 5 mm
for Panel Thickness min - max 0 - 0.2 "
Length (L) 222.9mm
Length (L2) 12.5mm
Min.Tensile Strength 225N
Offset Length 12.5mm
Panel Thickness max. 0.6 - 5.0mm
Weight/Unit 0.002403kg
Width (W) 5.1mm
CE Certification No
CSA Certified No
ELV compliant (Article 4 - 2) YES
Hazardous Goods No
Min. Extraction Force (N) 225N
Operating Temperature -40 °C to +105 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised (Yes/No) Yes
Country of Origin US
Customs Number 39269097
GTIN-13 / EAN 4031026494487
Packaging 1 - Height (m) 0.11m
Packaging 1 - Length (m) 0.58m
Packaging 1 - Qty 1000
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.01978
Packaging 1 - Weight (kg) 2.403001kg
Packaging 1 - Width (m) 0.31m
Packaging 3 - Height (m) 0.37465m
Packaging 3 - Length (m) 0.59055m
Packaging 3 - Qty 3000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0646
Packaging 3 - Weight (kg) 8.029003kg
Packaging 3 - Width (m) 0.2921m
Packaging 4 - Height (m) 0.964m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 36000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 0.925
Packaging 4 - Weight (kg) 149.228kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
