Connector clip for edge, black, 500pcs.
Nr. articol 133-00075
| Edge-Clip25-PA66HIRHS-BK
|
Copied
- Simply push per hand onto a plastic edge
Connector easily installed by simply pushing into place
Connection can be released (non-destructive)
Integrated metal clamp holds clip firmly in place
Clamp consists of double tempered spring steel
Ideal for applications where holes or adhesives are not suitable

Solicitați acum oferta dumneavoastră individuală
Solicitați oferta
Mai multe produse în acest grup de produse:
Application | Ec25 can be used with JAE connector 5pole (981801) and 6pole (978305). |
Anti rotation (Yes / No) | YES |
Colour | Black (BK) |
Fixation Method | Edge Clip |
Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
PART DESCRIPTION | Edge-Clip25-PA66HIRHS-BK |
Package Content | 500pcs. |
Package Content packed in | bag |
Product Group | Connector Clips for Edges |
Short Description | Connector Clip 18.9x19.6 mm, for edges, high impact modified, heat stabilised, black |
Type | Edge-Clip25 |
Weight/Unit | 0.002938kg |
|
|
Country of Origin | DE |
Customs Number | 39269097 |
GTIN-13 / EAN | 4031026239200 |
Packaging 1 - Height (m) | 0.06m |
Packaging 1 - Length (m) | 0.41m |
Packaging 1 - Qty | 500 |
Packaging 1 - Type | bag |
Packaging 1 - Volume (m³) | 0.007626m³ |
Packaging 1 - Weight (kg) | 1.490815kg |
Packaging 1 - Width (m) | 0.31m |
Packaging 2 - Type | carton |
Packaging 3 - Height (m) | 0.368m |
Packaging 3 - Length (m) | 0.584m |
Packaging 3 - Qty | 6000 |
Packaging 3 - Type | box |
Packaging 3 - Volume (m³) | 0.083m³ |
Packaging 3 - Weight (kg) | 18.72778kg |
Packaging 3 - Width (m) | 0.386m |
Packaging 4 - Height (m) | 1.249m |
Packaging 4 - Length (m) | 1.2m |
Packaging 4 - Qty | 72000 |
Packaging 4 - Type | pallet |
Packaging 4 - Volume (m³) | 1.199m³ |
Packaging 4 - Weight (kg) | 245.76kg |
Packaging 4 - Width (m) | 0.8m |
