Cable tie mount for screw fixation, ⌀11.2 - 20.8 mm, black, 500pcs.
Nr. articol 151-29301
| MSBT120-PA66HIRHS-BK
|
Copied
- For parallel routing of three bundles
- Retainer is fixed in the hole with BHT-tie
- Socket centres retainer in the hole and can protect tie from sharp edges
Solicitați oferta
Mai multe produse în acest grup de produse:
| Application | With its heavy duty fixing ability this product offers excellent performance for the truck, ship and construction vehicle industries. |
| Colour | Black (BK) |
| Fixation Method | Screw Mounting and Rivet |
| For Ties | BT130, BT105 |
| Key product features | vibration absorbing, for multiple routing |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | MSBT120-PA66HIRHS-BK |
| Package Content | 500pcs. |
| Package Content packed in | pack |
| Product Family | MSBT120 |
| Product Group | Fixing elements for BHT-ties for distance routing |
| Short Description | Fixing element for BHT-tie 48.3x16.5 mm, high impact, heat and UV stabilised, black |
| Type | MSBT120 |
| UV-Stabilised | Yes |
| Weight/Unit | 0.008kg |
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | Yes |
| Flammability | UL 94 HB |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| Operating Temperature, 1000h | +160 °C |
| Operating Temperature, 5000h | +125 °C |
| Operating Temperature, 500h | +165 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
|
|
|
| Country of Origin | US |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026312453 |
| Packaging 1 - Height (m) | 0.15m |
| Packaging 1 - Length (m) | 0.4m |
| Packaging 1 - Qty | 500 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.018m³ |
| Packaging 1 - Weight (kg) | 4.000001kg |
| Packaging 1 - Width (m) | 0.3m |
| Packaging 3 - Height (m) | 0.1508125m |
| Packaging 3 - Length (m) | 0.43656m |
| Packaging 3 - Qty | 500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0176m³ |
| Packaging 3 - Weight (kg) | 4.290001kg |
| Packaging 3 - Width (m) | 0.2667m |
| Packaging 4 - Height (m) | 1.201m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 14000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.153m³ |
| Packaging 4 - Weight (kg) | 142.12kg |
| Packaging 4 - Width (m) | 0.8m |
