Fixing tie for hole (round), outside serrated, ⌀1.6-30mm, black, 500pcs.
Nr. articol 126-00310 | OS180AH7S-LH-E-PA66HS-BK |

Copied
The disc at the head of the T50SOSSFT6.5E protects the bore against dirt and splashes.
A wide range of arrowhead fixing ties which are suitable for different panel thicknesses and hole diameters.
T50SOSKSFT6.5S2-E

    • Easy to install without the need for a tool
    • Arrowhead simply locks into place
    • Disc adjusts tie for pressures from various directions and minimises ingress of dust and dirt
    • Cable tie head always situated in a defined position
    • KSFT-types with specially rounded arrowhead minimise the assembly height
    Adăugați la lista de urmărire

    Solicitați acum oferta dumneavoastră individuală

     Solicitați oferta
    Downloads
    Application With a diverse range of fixing possibilities these ties are ideal for use in many different industries, including automotive, aerospace, white goods manufacture and panel building. This fastening solution is used to secure cable harnesses. We offer a variety of panel thicknesses and hole sizes to suit all kinds of application.
    Colour Black (BK)
    Fixation Method arrowhead
    Identification Plate Position none
    Material Polyamide 6.6, heat stabilised (PA66HS)
    Min.Tensile Strength 180N
    PART DESCRIPTION OS180AH7S-LH-E-PA66HS-BK
    Package Content 500pcs.
    Package Content packed in bag
    Product Family for round holes
    Product Group 1-piece fixing ties with arrowhead, with disc
    Releasable Closure (Yes/No) No
    Tie Closure plastic pawl
    Type OS180AH7S-LH-E
    Bundle ⌀ 1.6-30mm
    Bundle ⌀ max. 30mm
    Bundle ⌀ min. 1.6mm
    Length (L) 178.4mm
    Width (W) 5.3mm
    for Hole ⌀ (FH) 6.8 - 7.2 mm
    for Panel Thickness min - max 0.6 - 3.2 mm
    ROHS compliant Yes
    Specifications
    Country of Origin SG
    Customs Number 39269099
    GTIN-13 / EAN 4031026584768
    Packaging 1 - Qty 500
    Packaging 1 - Type bag
    ETIM 7.0 Key EC000046
    ETIM 8.0 Key EC000046
    ETIM 9.0 Key EC000046
    UNSPSC Key 39121703
