Pin connector terminal single grip, conductor sizes 0.5 - 1.5mm2, 100pcs, red
Art.-No. 924-00547 | 1P10-CU/PVC-RD |

Copied
Pin connector terminal, 1P10.
Pin Connector, Front View
Pin Connector, Side View

    • Recomennded for basic applications
    • Colour coded for easier identitfication
    • Additional copper sleeve for premium vibration
    • Copper terminal offers excellent elcetrical conductivity
    • PVC insulated
    • Packaged in resealable bags
    • REACH compliant
    Add to watchlist

    Request your individual offer now

     Request quote
    Downloads
    Application Single grip pin connectors are a practical choice for connecting wires to terminal blocks or plug-in connectors where a solid pin is needed. Ideal for compact installations, they offer straightforward assembly and reliable contact. The PVC insulation supports electrical safety and helps reduce strain on the wire. Use with the HYYT1 crimping tool for consistent and efficient results.
    Colour Red (RD)
    Description PIN CONNECTOR RED S/GRIP 9MM PIN 0.5MM²1.5MM²
    Local order number 1P10
    Material Copper (CU), Polyvinylchloride (PVC)
    Max Current 19A
    Max Voltage 600V
    PART DESCRIPTION 1P10-CU/PVC-RD
    Package Content 100pcs.
    Package Content packed in bag
    Product Family Single Grip Pre-Insulated Terminals
    Product Group Pin Connectors
    Type 1P10
    ⌀ (D2) 2.00mm
    Conductor Size Range mm² 0.5-1.5mm²
    Diameter (D) 4.3mm
    Length (L) 19mm
    Length (L2) 10mm
    Length (L3) 10mm
    Operating Temperature +75 °C
    ROHS compliant Yes
    Specifications
    GTIN-13 / EAN 9349519006709
