Releasable cable tie, 730.0x12.5mm, Ø12.0-203.0mm, 1115N, black, 25pcs.
Cikkszám 115-41403 | RT250I-PA66UV-BK Részletek

  • Releasable and reusable cable tie
  • Suitable for larger and/or heavier bundles
  • Eyelet allows excess tail to be tucked neatly away
  • Available in black and natural colour
  • Extended trigger for simple and quick release of ties
  • Protected trigger to avoid accidental release
  • RT250 cable ties are inside serrated
mutasson többet

Kérje egyedi ajánlatát most

Application The RT250 is a releasable cable tie. Due to its minimum loop tensile strength of 1,115 N the cable tie is perfectly suited to fix larger and/or heavier bundles. RT250 can be opened and reused. UV-resistant cable ties manufactured from PA66W are recommended for outdoor applications. For shorter lengths REL250-Series can be offered.
Colour Black (BK)
Fixation Method Releasable Cable Tie
Identification Plate Position none
Key product features releasable
Material Polyamide 6.6, UV-stabilised (PA66UV)
Pack Cont. 25pcs.
Package Content packed in bag
PART DESCRIPTION RT250I-PA66UV-BK
Product Family RT250-Series up to 1115 N loop tensile strength
Product Group Cable ties inside serrated with tuckaway
Releasable Closure (Yes/No) Yes
Tie Closure plastic pawl
Variant Inside Serrated
Bundle Diameter max (metric) 203.0mm
Bundle ∅ 12.0-203.0mm
Bundle ∅ min. 12.0mm
Cable Tie Head Height (metric) 9.5mm
Cable Tie Head Length (metric) 22.4mm
Cable Tie Head Width (metric) 20mm
Length (L) 730.0mm
Min.Tensile Strength 1115N
Strap Width max. (G) 0.79"
Thickness (T) 2.2mm
Width (W) 12.5mm
CE Certification Yes
CSA Certified No
Flammability UL 94 V2
Operating Temperature -40 °C to +85 °C
Specifications
Specifications UL
UL Listed (US and Canada) No
UL Recognized (US and Canada) Yes
UL-File Number E64139
UV-Stabilised (Yes/No) Yes
Country of Origin MX
GTIN-13 / EAN 4031026312330
Packaging 3 - Height (m) 0.213m
Packaging 3 - Length (m) 0.845m
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.0423
Packaging 3 - Width (m) 0.235m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121703
