1-Piece Fixing Ties with Arrowhead T50RSF(E)

T50RSF(E) for max. bundle diameter 50,0 mm, Cikkszám: 111-85799

Tulajdonságok

  • Easy to assemble without the need for a tool
  • Fixing tie with arrowhead without wings
  • Arrowhead simply locks into place
  • Cable tie head always situated in defined position

Tanúsítványok

Felhasználás

The arrowhead designs allows these ties to be used in areas with limited space.

T50RSF(E) for max. bundle diameter 50,0 mm az alábbi iparágban használhatóak

  • Automotive Industry Automotive Industry
  • Electronics Industry Electronics Industry
  • Defence Industry Defence Industry
Application Tool MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK20, MK21, EVO7, EVO7SP, EVO9
Colour Natural (NA)
Description Short (BMEcat) (max. 150 characters) Fixing Tie 210x4.6 natural
Fixation Method Arrowhead
Identification Plate Position none
Pack Cont. 500pcs.
Package Quantity per pcs.
PART DESCRIPTION T50RSF(E)-PA66-NA
Product Family T50RSF(E) for max. bundle diameter 50,0 mm
Product Group 1-Piece Fixing Ties with Arrowhead
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Type T50RSF.NN6P
Variant Inside Serrated
Bundle ∅ max. 44.0mm
Bundle ∅ min. 3.0mm
for Hole ∅ (FH) 6.2 - 6.4 mm
for Panel Thickness min - max 2.9 - 3 mm
for Panel Thickness min - max 0.1 - 0.1 "
Height (H) 8.0mm
Length (L) 210mm
Min.Tensile Strength 225N
Panel Thickness max. 2.9 – 3.0mm
Thickness (T) 1.2mm
Width (W) 4.6mm
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2
Hazardous good No
Material Polyamide 6.6 (PA66)
Operating Temperature - °C -40 °C to +85 °C
Specifications
Specifications ANSI/UL 1565, ANSI/UL 62275, ANSI/UL 746B
UL Type 11
UL-File Number E64963
EAN / GTIN 5022660326059
Packaging 1 - Height (m) 0.078m
Packaging 1 - Length (m) 0.355m
Packaging 1 - Qty 500
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00734
Packaging 1 - Weight (kg) 0.785kg
Packaging 1 - Width (m) 0.265m
Packaging 3 - Height (m) 0.364m
Packaging 3 - Length (m) 0.563m
Packaging 3 - Qty 8000
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0777
Packaging 3 - Weight (kg) 13.513kg
Packaging 3 - Width (m) 0.379m
Packaging 4 - Height (m) 1.236m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 96000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.187
Packaging 4 - Weight (kg) 183.156kg
Packaging 4 - Width (m) 0.8m
Weight 0.785kg
ETIM 6.0 EC000046
ETIM 7.0 Key EC000046
