Connector clip for hole (oval), EWCAP-005-11, black, 1000pcs.
Cikkszám 133-00004
| STECKERHALTER-OVALFUSS-PA66HIRHS-BK
|
Copied
- Easy to install by simply pushing into place
- Connection can be released (non-destructive)
- One fit tree foot part can be used for a variety of panel thicknesses
- Disc covers the hole to prevent dust and dirt gaining access
Ajánlatkérés
More products in this product group:
| Anti rotation (Yes / No) | NO |
| Colour | Black (BK) |
| Material | Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS) |
| PART DESCRIPTION | STECKERHALTER-OVALFUSS-PA66HIRHS-BK |
| Package Content | 1000pcs. |
| Package Content packed in | bag |
| Product Family | With Arrowhead |
| Product Group | Connector Clips for Oval Holes |
| Short Description | Connector Clip, oval hole 6.2 - 12.2 mm, arrow head, high impact modified, heat stabilised, black - STECKERHALTER-OVALFUSS |
| Type | STECKERHALTER-OVALFUSS |
| Typical Application | The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. These parts are related to a connector and then secured to a surface depending on the requirement |
| Weight/Unit | 0.000965kg |
|
|
|
| Country of Origin | FR |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026228303 |
| Packaging 1 - Height (m) | 0.055m |
| Packaging 1 - Length (m) | 0.34m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.006919m³ |
| Packaging 1 - Weight (kg) | 0.965kg |
| Packaging 1 - Width (m) | 0.37m |
| Packaging 3 - Height (m) | 0.368m |
| Packaging 3 - Length (m) | 0.584m |
| Packaging 3 - Qty | 12000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.083m³ |
| Packaging 3 - Weight (kg) | 12.4kg |
| Packaging 3 - Width (m) | 0.386m |
| Packaging 4 - Height (m) | 1.248m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 144000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.198m³ |
| Packaging 4 - Weight (kg) | 169.8kg |
| Packaging 4 - Width (m) | 0.8m |
