Self-closing polyester sleeving : Twist-In 29

Self-closing sleeving, 25 - 29 mm, PET, black, 2 mCikkszám: 170-01016

Tulajdonságok

  • Self-closing sleeve made of sturdy polyester
  • Provides very good protection against abrasion
  • Ideal for retro-fitting
  • Quick and easy installation and removal
  • Allows for inspection and maintenance

Tanúsítványok

Felhasználás

Helagaine Twist-In is used to bundle and protect pre-terminated cables in machine-building and automation, electrical installations and automobile and truck manufacturing.

HelaGaine Twist-In is also available in practical 2m and 5m lengths for use in the home or office.

Application Tool HSG0
Colour Black (BK)
Open, post termination (Yes/No) Yes
Pack Cont. 2m
Package Quantity per bag
PART DESCRIPTION Twist-In 29-PET-BK
Product Family Helagaine Twist-In
Product Group Self-closing polyester sleeving
Short Description Self-closing sleeving, 25 - 29 mm, PET, black, 2 m
Bundle ∅ max. 29mm
Bundle ∅ min. 25mm
Nominal ∅ 29mm
Wall (WT) 0.9mm
ELV compliant (Article 4 - 2) YES
Flammability self-extinguishing, FMVSS 302
Halogenfree Yes
Hazardous good No
Material Polyester (PET)
Melting Point +255 °C
Operating Temperature - °C -50 °C to +125 °C
Specifications
Specifications ANSI/NFPA 70
UL OCD link Link
UL Recognized (US and Canada) Yes
UL-File Number E197993
GTIN-13 / EAN 4031026453941
Packaging 1 - Height (m) 0.06m
Packaging 1 - Length (m) 0.44m
Packaging 1 - Qty 1
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.00832
Packaging 1 - Weight (kg) 0.088001kg
Packaging 1 - Width (m) 0.315m
Packaging 3 - Height (m) 0.145m
Packaging 3 - Length (m) 0.375m
Packaging 3 - Qty 5
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0207
Packaging 3 - Weight (kg) 0.94kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.305m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 240
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.253
Packaging 4 - Weight (kg) 66.12kg
Packaging 4 - Width (m) 0.8m
Reel Length 2m
ETIM 6.0 EC001182
ETIM 7.0 Key EC001182
