Corrugated tube clip for hole (oval), Ø24.0mm, black, 100pcs.
Številka proizvoda 151-02266 | RCC D24-PA66HIRHS-BK Podrobnosti

  • Clamps for corrugated tubing for a variety of nominal diameters
  • Arrowhead simply locks into place
  • Tube is guided accurately by clicking
  • Axial slipping is prevented by the inside profile of the clamp
  • Type RCCD for oval holes 6.2 x 12.2 mm
  • OCTCSFT6,5 clamp for corrugated tubes for nom. diamter of 55-80 mm.
  • CTC-L profile clamp can also fastened to a metal edge
prikaži več izdelkov

Zahtevajte svojo individualno ponudbo zdaj

Application These clamps are used for example in the automotive industry, in the production of cable harnesses and in the electrical industry. Their quick and easy mounting is the reason for their universal success wherever corrugated tubing and pipes have to be fixed quickly and securely.
Colour Black (BK)
Fixation Method with Arrowhead / Push Mount (Mounts)
Key product features for convoluted tubes or with rib
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Pack Cont. 100pcs.
Package Content packed in bag
PART DESCRIPTION RCC D24-PA66HIRHS-BK
Product Group Fixing Elements for Corrugated Tubing, with Arrowhead
Attach to Ø 24.0mm
for Hole ∅ (FH) 6.2 x 12.2 mm
for Panel Thickness min - max 0.7 - 2.5 mm
Height (H) 33.0mm
Length (L) 33.0mm
Nominal ∅ 24.0mm
Panel Thickness max. 0.7 - 2.5mm
Weight/Unit 0.0052kg
Width (W) 22.0mm
ELV compliant (Article 4 - 2) YES
Flammability UL 94 HB
Hazardous Goods No
Operating Temperature -40 °C to +105 °C
Specifications
Country of Origin PL
Customs Number 39269097
GTIN-13 / EAN 4031026214603
Packaging 1 - Height (m) 0.15m
Packaging 1 - Length (m) 0.3m
Packaging 1 - Qty 100
Packaging 1 - Type bag
Packaging 1 - Volume (m³) 0.0117
Packaging 1 - Weight (kg) 0.533862kg
Packaging 1 - Width (m) 0.26m
Packaging 3 - Height (m) 0.368m
Packaging 3 - Length (m) 0.584m
Packaging 3 - Qty 2000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.083
Packaging 3 - Weight (kg) 11.49724kg
Packaging 3 - Width (m) 0.386m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 24000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 159.0kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000464
ETIM 8.0 Key EC000464
ETIM 9.0 Key EC000464
UNSPSC Key 39121702
