Fixing tie for stud, outside serrated, Ø1.0-35.0mm, grey, 1000pcs.
Cikkszám 157-00151 | T50SOSSB5-High-E-C-CC-PA66HS-GY Részletek

  • One-piece fixing ties
  • High specification materials
  • Superior design
  • Suitable for complex applications

Kérje egyedi ajánlatát most

Application Primarily designed for use in the automotive industry, these parts can be used in a wide variety of applications where weld studs or ISO bolts are used and cables need to be bundled and secured.
Application Tool EVOcut, MK9P, MK9P w/ Upper air, MK10-SB, MK21, EVO7, EVO7SP, EVO9, EVO9SP, EVO9HT
Colour Grey (GY)
Fixation Method Stud Mount
Identification Plate Position none
Material Polyamide 6.6, heat stabilised (PA66HS)
Pack Cont. 1000pcs.
Package Content packed in box
PART DESCRIPTION T50SOSSB5-High-E-C-CC-PA66HS-GY
Product Group 1-Piece Fixing Ties for Weld, moveable
Releasable Closure (Yes/No) No
Tie Closure plastic pawl
Variant Outside Serrated
Bundle Diameter max (metric) 35.0mm
Bundle ∅ 1.0-35.0mm
Bundle ∅ min. 1.0mm
Fixing Hole Shape Oval
Length (L) 167.0mm
Max Stud Length 14.2mm
Max Stud Length 0.56"
Min.Tensile Strength 222.4N
Stud ∅ 5.0 mm, M6
Stud ∅ 0.20 ", 0.24"
Width (W) 5.0mm
CE Certification No
CSA Certified No
Flammability UL 94 V2
Operating Temperature -40 °C to +125 °C
Specifications
UL Listed (US and Canada) No
UL Recognized (US and Canada) No
UV-Stabilised (Yes/No) No
Country of Origin US
GTIN-13 / EAN 4031026459004
Packaging 3 - Height (m) 0.3730625m
Packaging 3 - Length (m) 0.587375m
Packaging 3 - Qty 3000
Packaging 3 - Type box
Packaging 3 - Volume (m³) 0.063
Packaging 3 - Weight (kg) 9.67kg
Packaging 3 - Width (m) 0.2873375m
ETIM 7.0 Key EC000046
ETIM 8.0 Key EC000046
ETIM 9.0 Key EC000046
UNSPSC Key 39121717
