Heat Shrinkable Tubing 2:1 flame retardant halogen free 9.5/4.8 black
Cikkszám 315-50950
| TR27-9.5/4.8-PO-X-BK
|
Copied
- Thin wall, flexible polyolefin tubing
Optional available with adhesive or as thick wall version (SR27)
Halogen free and excellent flame-retardant properties
Limited Fire Hazard
Low generation of toxic gases and corrosive acid
Low smoke generation
Meets various industrial standards
Kérje egyedi ajánlatát most
Ajánlatkérés
More products in this product group:
| Application | TR27 is used in applications where toxic emissions evolved in a fire must be minimised, e.g. for heavily populated buildings or safety sensitive areas like tunnels, hospitals, schools, theatres, mass transit vehicles and computer centres. |
| Behaviour at Heat Shock | not cracking, not dripping, not fluid |
| Colour | Black (BK) |
| Heat Shock Test | 4h/150°C |
| Material | Polyolefin, cross-linked (PO-X) |
| PART DESCRIPTION | TR27-9.5/4.8-PO-X-BK |
| Package Content | 60m |
| Package Content packed in | metre |
| Printable | No |
| Product Family | TR27 |
| Product Group | Heat shrinkable tubing 2:1 - Flame retardant |
| Short Description | Heat Shrinkable Tubing 2:1 flame retardant halogen free 9.5/4.8 black |
| Shrink Ratio | 2:1 |
| Size | 3/8" |
| Type | TR27-9.5/4.8 |
| Variant | Thin-Wall |
| Weight/Unit | 0.02368kg |
| With inner glue (Yes/No) | No |
Letöltés
| Dielectric Strength | 15kV/mm |
| Dielectric Strength test method | IEC 684 P2 |
| ELV compliant (Article 4 - 2) | YES |
| Elongation at break (min.) | 200% |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Limited Fire Hazard | Yes |
| Min. Shrink Temperature - °C | +115 °C |
| Operating Temperature | -40 °C to +105 °C |
| ROHS compliant | Yes |
| Self extinguishing | Yes |
| Specifications |
|
| Specifications | EN 45545-2 |
| Tensile Strength | 7MPa |
| Volume Resistance | 10¹³ Ω cm |
| Water Absorption | 1.0% |
| Country of Origin | JP |
| Customs Number | 39173200 |
| GTIN-13 / EAN | 4031026224633 |
| Packaging 1 - Height (m) | 0.097m |
| Packaging 1 - Length (m) | 0.39m |
| Packaging 1 - Qty | 60 |
| Packaging 1 - Type | reel |
| Packaging 1 - Volume (m³) | 0.0147537m³ |
| Packaging 1 - Weight (kg) | 1.421kg |
| Packaging 1 - Width (m) | 0.39m |
| Packaging 3 - Height (m) | 0.11m |
| Packaging 3 - Length (m) | 0.4m |
| Packaging 3 - Qty | 60 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 0.0176m³ |
| Packaging 3 - Weight (kg) | 1.921kg |
| Packaging 3 - Width (m) | 0.4m |
| Packaging 4 - Height (m) | 1.244m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 3600 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.194m³ |
| Packaging 4 - Weight (kg) | 136.248kg |
| Packaging 4 - Width (m) | 0.8m |
| Reel Length | 60.0m |
