25/02/2021

EdgeClip with TwistLock for cables 6.5 - 8.5 mm : EC1-3TL7OTP

Številka proizvoda: 151-02588

Lastnosti

  • Simply push per hand onto a plastic edge
  • simply twist to secure cables, and untwist for easy removals or additions
  • One twist has up to 20 N of tensile strength, for safe and secure fastening
  • Rounded edges protect cables and fingers from cuts and abrasions
  • For edges of 1-3 mm
  • Integrated metal clamp holds clip firmly in place
  • Clamp consists of double tempered spring steel
  • Ideal for applications where holes or adhesives are not suitable

Certifikati in standardi

Uporaba

Edge Clips are used in the automotive industries and electrical industries and when it is impossible to drill holes or no other fixing points are available.

Colour Black (BK)
Fixation Method EdgeClip, top
Pack Cont. 500pcs.
Package Quantity per Bag
PART DESCRIPTION EC1-3TL7OTP-PA66HIRHS-BK
Product Group EdgeClip with TwistLock for cables 6.5 - 8.5 mm
Type EC1-3TL70TP_PA66HIRHS_BK
Attach to Ø 6.5 - 8.5
Bundle ∅ max. 8.5mm
Bundle ∅ min. 6.5mm
for Panel Thickness min - max 1 - 3 mm
Height (H) 11.9mm
Height (H2) 33.15mm
Length (L) 15.0mm
Panel Thickness max. 1.0 - 3.0mm
Width (W) 9.2mm
ELV compliant Dir. Art. 4 (2) YES
Hazardous good No
Material Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Operating Temperature - °C -40 °C to +105 °C, (+105 °C for 500 h)
Specifications
EAN / GTIN-13 4031026614632
Packaging 1 - Height (m) 0.15m
Packaging 1 - Length (m) 0.3m
Packaging 1 - Qty 500
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.0117
Packaging 1 - Weight (kg) 0.813862kg
Packaging 1 - Width (m) 0.26m
Packaging 3 - Height (m) 0.184m
Packaging 3 - Length (m) 0.58m
Packaging 3 - Qty 6000
Packaging 3 - Type Carton
Packaging 3 - Volume (m³) 0.0406
Packaging 3 - Weight (kg) 10.366344kg
Packaging 3 - Width (m) 0.38m
Packaging 4 - Height (m) 1.248m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 144000
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 1.198
Packaging 4 - Weight (kg) 269.832kg
Packaging 4 - Width (m) 0.8m
Weight 0.8kg
ETIM 6.0 EC000449
ETIM 7.0 Key EC000449
