Cable Tie Mounts Q-Series : QM30A

Screw Fixing Cable Tie Mount self adhesive 30 x 30 black, Številka proizvoda: 151-10915

Lastnosti

  • Screwable or self adhesive versions
  • Perfect for combination with Q-ties
  • 4-way entry for cable ties
  • Adhesive with high pull-off force
  • Locks cable tie in vertical position, means the hands are free to apply cables

Certifikati in standardi

Uporaba

Q-mounts are ideally suited for holding our innovative Q-ties in place. They would perfectly fit to all applications where a reliable and durable fixation is required. Self adhesive versions of our Q-Mounts are suitable for applications where using screws, nuts, bolts or drilling holes to fix cables is problematic, or not the first choice.

Q-Mount Series QMA, self adhesive, screwable so primerne za uporabo v naslednjih industrijskih panogah

Colour Black (BK)
Fixation Method Screw Mounting and Adhesive
Pack Cont. 100pcs.
Package Quantity per Bag
PART DESCRIPTION QM30A-PA66-BK
Product Family Q-Mount Series QMA, self adhesive, screwable
Product Group Cable Tie Mounts Q-Series
Short Description Screw Fixing Cable Tie Mount self adhesive 30 x 30 black
Type QM30A-PA66-BK-C1
Fixing Hole Centres (F) 21.0mm
Fixing Hole Centres (F) (imperial) 0.83"
for Hole ∅ (FH) 4.1 mm
Height (H) 4.5mm
Length (L) 30.0mm
Strap Width max. (G) 5.1mm
Strap Width max. (G) (imperial) 0.2"
Width (W) 30.0mm
Adhesive Synthetic rubber with base of polyethylene foam
Adhesive Operating Temperature -40 °C to +60 °C
ELV compliant Dir. Art. 4 (2) YES
Flammability UL 94 V2 (excluding adhesive)
Halogenfree Yes
Hazardous good No
Material Polyamide 6.6 (PA66)
Operating Temperature - °C -40 °C to +85 °C
Specifications
EAN / GTIN 4031026413785
Packaging 1 - Height (m) 0.1m
Packaging 1 - Length (m) 0.22m
Packaging 1 - Qty 100
Packaging 1 - Type Bag
Packaging 1 - Volume (m³) 0.00528
Packaging 1 - Weight (kg) 0.1714kg
Packaging 1 - Width (m) 0.24m
Weight 0.1614kg
ETIM 6.0 EC000449
ETIM 7.0 Key EC000449
UNSPSC Key 39121717
