Cable tie inside serrated, 100.0x2.5mm, ⌀1.5-22.0mm, natural, 100pcs.
Číslo dílu 111-01919
| T18R-PA66-NA
|
Copied
- Available in a wide range of materials and sizes
- High tensile strength with very low insertion force
- Only high quality plastic is used meeting recycling targets
- Inside serrated cable ties for a strong hold onto bundles
- Ergonomic bent tail offers quick and simple installation
- Easy application either manually or with an application tool
ukázat více
Zobrazit méně
Vyžádat nabídku
Více výrobků v této skupině výrobků:
| Application | T-Series cable ties for bundling and securing of cables, pipes and hoses. These cable ties can be used for nearly all kind of applications. |
| Application Method | Quick, simple fixing by hand or with HellermannTyton tensioning tools |
| Colour | Natural (NA) |
| Identification Plate Position | none |
| Material | Polyamide 6.6 (PA66) |
| Min.Tensile Strength | 80N |
| PART DESCRIPTION | T18R-PA66-NA |
| Package Content | 100pcs. |
| Package Content packed in | bag |
| Product Family | T-Series in PA66 natural |
| Product Group | Cable ties polyamide 6.6 standard |
| Releasable Closure (Yes/No) | No |
| Short Description | Cable Tie 100x2.5 natural |
| Tie Closure | plastic pawl |
| Type | T18R |
| UV-Stabilised | No |
| Variant | Inside Serrated |
| Weight/Unit | 0.00028kg |
| ELV compliant (Article 4 - 2) | Yes |
| Flammability | UL 94 V2 |
| Halogen-free | Yes |
| Hazardous Goods | No |
| Nato number | 5975-12-161-4591 |
| Operating Temperature | -40 °C to +85 °C |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | ANSI/UL 62275, CSA -C22.2 no. 62275 |
| UL File link | Odkaz |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | E85319 |
|
|
|
| Country of Origin | SG |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026104225 |
| Packaging 1 - Height (m) | 0.017m |
| Packaging 1 - Length (m) | 0.18m |
| Packaging 1 - Qty | 100 |
| Packaging 1 - Type | bag |
| Packaging 1 - Volume (m³) | 0.0003213m³ |
| Packaging 1 - Weight (kg) | 0.032kg |
| Packaging 1 - Width (m) | 0.105m |
| Packaging 2 - Height (m) | 0.188m |
| Packaging 2 - Length (m) | 0.136m |
| Packaging 2 - Qty | 8000 |
| Packaging 2 - Type | box |
| Packaging 2 - Volume (m³) | 0.0096m³ |
| Packaging 2 - Weight (kg) | 2.71kg |
| Packaging 2 - Width (m) | 0.377m |
| Packaging 3 - Height (m) | 0.218m |
| Packaging 3 - Length (m) | 0.599m |
| Packaging 3 - Qty | 32000 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0522m³ |
| Packaging 3 - Weight (kg) | 11.59kg |
| Packaging 3 - Width (m) | 0.4m |
| Packaging 4 - Height (m) | 1.234m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 640000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.185m³ |
| Packaging 4 - Weight (kg) | 253.8kg |
| Packaging 4 - Width (m) | 0.8m |
