End Cap with Thermoplastic Adhesive for Low Voltage black, PO-X, up to 3:1
Číslo dílu 416-14047 | 1614-1-B5W2-PO-X-BK Podrobnosti na

  • Seal cables during storage or transportation
  • Insulating cap for live LV cables (0.6/1kV)
  • Adhesive lining for excellent environmental seal
  • High shrink ratio to minimise number of sizes needed
  • Can be fitted with air valves for pressurised cable applications
  • High shrink ratio to minimise number of sizes needed
ukázat více

Vyžádejte si nyní individuální nabídku

Application End caps are suitable for use on both polymeric and paper insulated, lead jacketed cables which may include aluminium or steel armouring.
Application Tool H6100, E4500, CHG900
Colour Black (BK)
Material Polyolefin, cross-linked (PO-X)
Pack Cont. 300pcs.
Package Content packed in carton
PART DESCRIPTION 1614-1-B5W2-PO-X-BK
Product Family Helashrink 1600 Series, low voltage
Product Group End Caps
Short Description End Cap with Thermoplastic Adhesive for Low Voltage black, PO-X, up to 3:1
Shrink Ratio up to 3:1
Size 1-1/2"
Bundle Diameter max (metric) 32.0mm
Bundle ∅ 16.0-32.0mm
Bundle ∅ min. 16.0mm
Flexibility semi rigid
HW ± 20 % 3.3mm
Max Voltage 600V
P ± 10 % 75.0mm
Recov. ∅ d max. 15.0mm
Supplied ∅ D min. 40.0mm
W ± 20 % 3.3mm
Weight/Unit 0.018kg
∅H max. b 15.0mm
∅H min. a 40.0mm
Adhesive W2
Dielectric Strength 15kV/mm
ELV compliant (Article 4 - 2) YES
Flammability ASTM D635
Hazardous Goods No
Min. Shrink Temperature - °C +135 °C
Operating Temperature -55 °C to +80 °C
Specifications
Country of Origin CN
Customs Number 39174000
GTIN-13 / EAN 5022660436529
Packaging 2 - Weight (kg) 0.5kg
Packaging 3 - Height (m) 0.37m
Packaging 3 - Length (m) 0.54m
Packaging 3 - Qty 300
Packaging 3 - Type carton
Packaging 3 - Volume (m³) 0.0689
Packaging 3 - Weight (kg) 5.9kg
Packaging 3 - Width (m) 0.345m
Packaging 4 - Height (m) 8.85m
Packaging 4 - Length (m) 1.2m
Packaging 4 - Qty 2400
Packaging 4 - Type pallet
Packaging 4 - Volume (m³) 8.496
Packaging 4 - Weight (kg) 68.2kg
Packaging 4 - Width (m) 0.8m
ETIM 7.0 Key EC000218
ETIM 8.0 Key EC000218
ETIM 9.0 Key EC000218
UNSPSC Key 39121721
