4-Way Outlet Shapes, Breakout Boots
Číslo dílu 404-42022
| 442-1-B8W-PO-X-BK
|
Copied
- Easy, time-saving insulation of cable branch point where it splits into single wires
Made of tough, cross-linked, Polyolefin
Adhesive is applied to relieve mechanical tension in cable harnesses

Vyžádejte si nyní individuální nabídku
Vyžádat nabídku
Více výrobků v této skupině výrobků:
Application | Cable breakouts are manufactured from a tough cross-linked flame retarded polyolefin. This allows the breakouts to be used for both interior and exterior applications. The adhesive liner offers excellent electrical and mechanical protection and are available for 2, 3, 4, 5 and 6 core cables. |
Colour | Black (BK) |
Material | Polyolefin, cross-linked (PO-X) |
PART DESCRIPTION | 442-1-B8W-PO-X-BK |
Package Content | 1pc. |
Package Content packed in | bag |
Product Family | Helashrink 400 Series, in line, low voltage |
Product Group | 4-Way Outlet Shapes, Breakout Boots |
Shrink Ratio | up to 3:1 |
Type | 442-1-B8W |
Variant | For 4-core cables |
Weight/Unit | 0.14kg |
Adhesive | WM250 |
Dielectric Strength | 15kV/mm |
Dielectric Strength test method | ASTM D2671 |
ELV compliant (Article 4 - 2) | YES |
Flammability | ASTM D635 |
Hazardous Goods | No |
Min. Shrink Temperature - °C | +135 °C |
Operating Temperature | -55 °C to +100 °C |
ROHS compliant | Yes |
Shelf Life | 5 years |
Specifications |
![]() |
Tensile Strength | 15MPa |
