Corrugated tubing, flame retardant, nom⌀21mm, OD=21.2mm, ID=16.7mm, black, 50m
Číslo dílu 166-11403
| HG-FR21-PA6FR-BK
|
Copied
- Highly flame retardant (UL94 V0)
- Low smoke, low toxicity
- Very flexible and high fatigue life
- High impact strength, recovers if crushed
- Abrasion resistant
- Highly resistant to solvents and oils
- Free of halogen, sulphur and phosphorus
- Colour: black
ukázat více
Zobrazit méně
Vyžádat nabídku
Více výrobků v této skupině výrobků:
| Colour | Black (BK) |
| Key product features | flame retardant |
| Material | Polyamide 6, flame retardant (PA6FR) |
| Min.Tensile Strength | 400N |
| PART DESCRIPTION | HG-FR21-PA6FR-BK |
| Package Content | 50m |
| Package Content packed in | reel |
| Pitch Type | fine |
| Product Family | HG-FR PA6 Flame Retardant |
| Product Group | Non-Metallic Conduits |
| Short Description | Flame-retardant standard weight corrugated flexible conduit PA6 ø21mm reel 50m |
| Type | HG-FR21 |
| Typical Application | Flame-retardant standard weight corrugated flexible conduit is used where high fire-protection is required, including railway vehicles, tunnels and underground stations as well as public buildings. |
| Weight/Unit | 0.0612kg |
| CE Certification | Yes |
| ELV compliant (Article 4 - 2) | Yes |
| EN61386 Classification | 24244066-210 |
| Flammability | UL 94 V0 |
| Halogen-free | Yes |
| Hazardous Goods | No |
| IP-Rating | IP66 (in conjunction with HG fittings) |
| Oil resistant | Yes |
| Operating Temperature | -40 °C to +120 °C |
| Operating Temperature Moving | -20 °C to +100 °C |
| ROHS compliant | Yes |
| Specifications |
|
| Specifications | ANSI/UL 1696, BS EN 61386-23, CSA -C22.2 No.227.3, EN 45545-2 |
| UL File link | Odkaz |
| UL Recognized (US and Canada) | Yes |
| UL-File Number | E325250 |
|
|
|
| Country of Origin | GB |
| Customs Number | 39173200 |
| GTIN-13 / EAN | 4031026302591 |
| Packaging 1 - Height (m) | 0.22m |
| Packaging 1 - Length (m) | 0.48m |
| Packaging 1 - Qty | 50 |
| Packaging 1 - Type | reel |
| Packaging 1 - Volume (m³) | 0.050688m³ |
| Packaging 1 - Weight (kg) | 3.06kg |
| Packaging 1 - Width (m) | 0.48m |
| Packaging 3 - Height (m) | 1.12m |
| Packaging 3 - Length (m) | 1.2m |
| Packaging 3 - Qty | 1000 |
| Packaging 3 - Type | carton |
| Packaging 3 - Volume (m³) | 1.0752m³ |
| Packaging 3 - Weight (kg) | 65.4kg |
| Packaging 3 - Width (m) | 0.8m |
| Packaging 4 - Height (m) | 1.264m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 1000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.213m³ |
| Packaging 4 - Weight (kg) | 87.4kg |
| Packaging 4 - Width (m) | 0.8m |
| Reel Length | 50m |
