1-Piece Fixing Ties with Arrowhead, with Wings : T50SSFM
1-Piece Fixing Tie 160x4.6 mm, with Arrowhead and Wings, naturalČíslo dílu: 111-85739
Vlastnosti
- Easy to assemble without the need for a tool
- Cable tie head always situated in defined position
- Arrowhead simply locks into place
- Supporting legs provide a secure and firm fixing in areas where space is limited
Certifikáty a normy
Použití
For bundling and fixing of cable harnesses, pipes and hoses in many different industries, including automotive, aerospace, white goods manufacturing and panel building.
Více výrobků v této skupině výrobků
1-Piece Fixing Ties with Arrowhead, with Wings >| Application Tool | MK3PNSP2, MK3SP, MK6, MK7HT, MK7P, MK20, MK21, EVO7, EVO7SP, EVO9 |
| Colour | Natural (NA) |
| Fixation Method | Arrowhead |
| Identification Plate Position | none |
| Pack Cont. | 1000pcs. |
| Package Quantity per | pcs. |
| PART DESCRIPTION | T50SSFM-PA66-NA |
| Product Family | 1-piece fixing ties with arrowhead, with wings, for round holes |
| Product Group | 1-Piece Fixing Ties with Arrowhead, with Wings |
| Releasable Closure (Yes/No) | No |
| Short Description | 1-Piece Fixing Tie 160x4.6 mm, with Arrowhead and Wings, natural |
| Tie Closure | plastic pawl |
| Type | T50SSFM.NN903 |
| Variant | Inside Serrated |
| Bundle ∅ max. | 35.0mm |
| Bundle ∅ min. | 1.5mm |
| for Hole ∅ (FH) | 6.0 - 6.6 mm |
| for Panel Thickness min - max | 0.7 - 3 mm |
| for Panel Thickness min - max | 0 - 0.1 " |
| Height (H) | 5.6mm |
| Length (L) | 160mm |
| Min.Tensile Strength | 222N |
| Panel Thickness max. | 0.7 – 3.0mm |
| Width (W) | 4.6mm |
| Width (W2) | 14.7mm |
| ELV compliant Dir. Art. 4 (2) | YES |
| Flammability | UL 94 V2 |
| Hazardous good | No |
| Material | Polyamide 6.6 (PA66) |
| Operating Temperature - °C | -40 °C to +85 °C |
| Specifications |
|
|
|
|
| GTIN-13 / EAN | 5022660326844 |
| Packaging 1 - Height (m) | 0.06m |
| Packaging 1 - Length (m) | 0.48m |
| Packaging 1 - Qty | 1000 |
| Packaging 1 - Type | Bag |
| Packaging 1 - Volume (m³) | 0.01282m³ |
| Packaging 1 - Weight (kg) | 1.346kg |
| Packaging 1 - Width (m) | 0.445m |
| Packaging 3 - Height (m) | 0.364m |
| Packaging 3 - Length (m) | 0.563m |
| Packaging 3 - Qty | 8000 |
| Packaging 3 - Type | Carton |
| Packaging 3 - Volume (m³) | 0.0777m³ |
| Packaging 3 - Weight (kg) | 11.729kg |
| Packaging 3 - Width (m) | 0.379m |
| Packaging 4 - Height (m) | 1.236m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 96000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.187m³ |
| Packaging 4 - Weight (kg) | 161.748kg |
| Packaging 4 - Width (m) | 0.8m |
| ETIM 6.0 | EC000046 |
| ETIM 7.0 Key | EC000046 |
