Connector clip, EWCAP-005-11, black, 2500pcs.
???product.artNr??? 151-01044
| SB5CC-PA66HIRHSUV-BK
|
???product.copy???
- Connector easily installed by simply pushing into place
- Connection can be released (non-destructive)
???product.productgroup.title???:
| ???product.application??? | The Connector Clips used here have been designed for electronic cables and cable sets used in the automotive industry. The Connector Clips are related to a Connector and then secured to a surface depending on the requirement. |
| Colour | Black (BK) |
| Material | Polyamide 6.6, high impact modified, heat and UV-stabilised (PA66HIRHSUV) |
| PART DESCRIPTION | SB5CC-PA66HIRHSUV-BK |
| Package Content | 2500pcs. |
| Package Content packed in | carton |
| Product Family | with Stud |
| Product Group | Connector clips for weld studs |
| Type | SB5CC |
| UV-Stabilised | Yes |
| Weight/Unit | 0.002kg |
| CE Certification | No |
| CSA Certified | No |
| ELV compliant (Article 4 - 2) | Yes |
| Hazardous Goods | No |
| Operating Temperature | -40 °C to +105 °C |
| Operating Temperature, 1000h | +160 °C |
| Operating Temperature, 5000h | +125 °C |
| Operating Temperature, 500h | +165 °C |
| ROHS compliant | Yes |
| Specifications |
|
| UL Listed (US and Canada) | No |
| UL Listed (US) | No |
| UL Recognized (US and Canada) | No |
| UL Recognized (US) | No |
|
|
|
| Country of Origin | US |
| Customs Number | 39269097 |
| GTIN-13 / EAN | 4031026493244 |
| Packaging 1 - Type | bag |
| Packaging 3 - Height (m) | 0.20955m |
| Packaging 3 - Length (m) | 0.5175m |
| Packaging 3 - Qty | 2500 |
| Packaging 3 - Type | box |
| Packaging 3 - Volume (m³) | 0.0344m³ |
| Packaging 3 - Weight (kg) | 5.62kg |
| Packaging 3 - Width (m) | 0.3175m |
| Packaging 4 - Height (m) | 1.209m |
| Packaging 4 - Length (m) | 1.2m |
| Packaging 4 - Qty | 50000 |
| Packaging 4 - Type | pallet |
| Packaging 4 - Volume (m³) | 1.161m³ |
| Packaging 4 - Weight (kg) | 134.4kg |
| Packaging 4 - Width (m) | 0.8m |
